Porsche Cayenne Turbo III (2017-2023) front passenger side air bag deactivate key operated switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger side air bag deactivate key operated switch, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger side air bag deactivate key operated switch (1 of 1)
ACTIVE BONNET DRIVER +
AIR BAG 1-
AIR BAG 2+
AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE)
AIR BAG PULSE
ANALOG GND
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
CRASH OUTPUT (PWM)
DRIVER SIDE AIR BAG PRESSURE SENSOR
DRIVER SIDE KNEE AIR BAG IGNITER
DRV AIR BAG IGNITER
DRV AIR BAG STAGE 1 -
DRV AIR BAG STAGE 2 -
DRV PASS BELT TENSIONER +
DRV SIDE KNEE AIR BAG +
EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT
FRONT FUSE BOX
FRONT PASS SIDE AIR BAG IGNITER
FRONT PASSENGER SIDE AIR BAG DEACTIVATE KEY OPERATED SWITCH
FRONT PASSENGER SIDE AIR BAG PRESSURE SENSOR
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
FRT PASS BELT TENSIONER +
FUSE 10
FUSE HOLDER E
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
NEGATIVE
PASS AIR BAG STAGE 2 -
PASS REAR SIDE AIR BAG IGNITER
PASS SIDE KNEE AIR BAG +
POSITIVE
PRESSURE SENSOR
REAR PASS SIDE BELT TENSIONER IGNITER
REAR SIDE AIR BAG IGNITER -
RED WIRE
RIGHT REAR BELT SWITCH
SHIELD
STEERING COLUMN ELECTRONICS CONTROL UNIT
TERM 30
WHT WIRE
WIDTH MODULATION
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (1 of 5) -> FRONT PASSENGER SIDE AIR BAG DEACTIVATE KEY OPERATED SWITCH
