Porsche Cayenne Turbo III (2017-2023) front anti-roll bar control unit Wiring diagram
This page shows the only wiring diagram for the component.front anti-roll bar control unit, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front anti-roll bar control unit (1 of 1)
BLK/GRY WIRE
BRN WIRE
CAN CHASSIS HIGH
CAN CHASSIS LOW
COMPUTER DATA LINES SYSTEM
FRONT ANTI-ROLL BAR CONTROL UNIT
FRONT FUSE BOX
FUSE 1
FUSE 8
FUSE HOLDER D
FUSE HOLDER K
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
N/A
ORG/BRN WIRE
ORG/GRY WIRE
POTENTIAL EQUALISATION
REAR ANTI-ROLL BAR CONTROL UNIT 2
RED/WHT WIRE
TERM 15
TERM 30
TERM 31
Go to component -> Dynamic chassis control circuit -> FRONT ANTI-ROLL BAR CONTROL UNIT
