Porsche Cayenne Turbo III (2017-2023) flexray 2- output pnk flexray 2+ output Wiring diagrams
This page contains all the electrical diagrams for the component. flexray 2- output pnk flexray 2+ output, in which he is found in the car Porsche Cayenne Turbo III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram flexray 2- output pnk flexray 2+ output (1 of 2)
AIR CONDITIONING SYSTEM
BLK/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CAN HIGH HYBRID
CAN HYBRID HIGH
CAN HYBRID LOW
CAN LOW HYBRID
CIRCULATION PUMP
COMPUTER DATA LINES SYSTEM
COOLANT PMP RLY
COOLANT PUMP RELAY
COOLANT SHORTAGE IND
COOLANT SHORTAGE INDICATOR SENDER 2
EANABLE RADIATOR FAN 1
EANABLE RADIATOR FAN 2
ENGINE/MOTOR CONTROL UNIT
FLEXRAY 2- OUTPUT PNK FLEXRAY 2+ OUTPUT WIRE
FRONT FUSE BOX
FUSE 11
FUSE 14
FUSE 3
FUSE CARRIER 4
FUSE HOLDER B
FUSE HOLDER K
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
HIGH VOLTAGE BATTERY 1
HIGH VOLTAGE BATTERY COOLANT PUMP
HOT AT ALL TIMES
LOCK
LOW TEMPERATURE CIRCUIT COOLANT PUMP 2
N/A
ORG/BRN WIRE
POSITIVE
PWM
PWM PUMP
PWM RADIATOR FAN 1
PWM RADIATOR FAN 2
RADIATOR FAN
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR RELAY
REAR FUSE BOX
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY CARRIER 6
TAN WIRE
TERM 30
TERM 30 RELAY
TERM 87
THERMAL MANAGEMENT CONTROL UNIT
UBATT
VIO/WHT WIRE
YEL/VIO WIRE
Go to component -> 3.0l turbo hybrid, hybrid cooling system circuit -> FLEXRAY 2- OUTPUT PNK FLEXRAY 2+ OUTPUT WIRE
