Porsche Cayenne Turbo III (2017-2023) except hybrid Wiring diagrams
This page contains all the electrical diagrams for the component. except hybrid, in which he is found in the car Porsche Cayenne Turbo III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram except hybrid (1 of 4)
AUTOMATIC GEARBOX CONTROL UNIT
BATTERY ISOLATION UNIT
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID
FLEXRAY 1-
FRONT FUSE BOX
FUSE 1
FUSE 2
FUSE HOLDER D
GRN WIRE
HOT AT ALL TIMES
N/A
NCA WIRE
ONBOARD SUPPLY CONTROL UNIT
PNK FLEXRAY 1+ WIRE
RED WIRE
RED/YEL WIRE
SERVOTRONIC CONTROL UNIT
STEERING FUSE
TERM 15
TERM 15 ACTIVATION
TERM 30
TERMINAL 30 WIRING JUNCTION BOX
YEL WIRE
Go to component -> Electronic power steering circuit -> EXCEPT HYBRID
Wiring diagram except hybrid (2 of 4)
BACKUP
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BODY GND
BRAKE LIGHT SWITCH
BRAKE SERVO CONTROL UNIT
BRN WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
CAN HIGH
CAN LOW
CENTRE TAIL LIGHT CLUSTER
CIRCUIT
COMPUTER DATA LINES SYSTEM
ENGINE/ MOTOR CONTROL UNIT
EXCEPT HYBRID
FRONT FUSE BOX
FUSE 15
FUSE 16
FUSE 5
FUSE HOLDER A
FUSE HOLDER D
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
HIGH MOUNTED STOP LIGHT
HOT W/ MAIN RELAY ENERGIZED
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
LAMPS)
LEFT BRAKE LIGHT
LEFT FRONT HEADLIGHT
LEFT FRONT TURN SIGNAL, SIDE LIGHT
LEFT NUMBER PLATE LIGHT
LEFT REAR INDICATOR
LEFT REVERSE LIGHT
LEFT SIDE MARKER LIGHT
LEFT TAIL LIGHT
LEFT TAIL LIGHT CLUSTER
LEFT TAIL/BRAKE LIGHT 1
LEFT TAIL/BRAKE LIGHT 2
LEFT TAIL/BRAKE LIGHT 3
LEFT TAIL/BRAKE LIGHT 4
LEFT TURN SIGNAL
MARKER LIGHT
N/A
NUMBER PLATE LIGHT +
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
RIGHT BRAKE LIGHT
RIGHT NUMBER PLATE LIGHT
RIGHT REAR INDICATOR
RIGHT REVERSE LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TAIL LIGHT
RIGHT TAIL/BRAKE LIGHT 1
RIGHT TAIL/BRAKE LIGHT 2
RIGHT TAIL/BRAKE LIGHT 3
RIGHT TAIL/BRAKE LIGHT 4
RIGHT TURN SIGNAL
TERM 15
TERM 30
TERM 30 1
TERM 31
TERM 58
TERM 87
TURN SIGNAL
VIO/RED WIRE
WHT/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> EXCEPT HYBRID
Wiring diagram except hybrid (3 of 4)
AIR BAG CONTROL UNIT
ALTERNATOR
BATTERY
BATTERY ISOLATION UNIT
BATTERY MONITOR CONTROL UNIT
BLK WIRE
BLU WIRE
BRAKE SERVO CONTROL UNIT
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID
FRONT FUSE BOX
FUSE
FUSE 1
FUSE 2
FUSE 2 N/A
FUSE 3
FUSE 3 N/A
FUSE 4
FUSE 4 N/A
FUSE CARRIER 4
FUSE CARRIER 5
GND LINE
HEATED WINDSCREEN CONTROL UNIT
N/A
NCA WIRE
RADIATOR FAN
REAR WHEEL STEERING CONTROL UNIT
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SERVOTRONIC CONTROL UNIT
STARTER
STEERING FUSE
TERM 30
TERMINAL 30 WIRING JUNCTION BOX
TO FUSE HOLDER H (DIAGRAM 7 OF 9)
TO MAIN RELAY (DIAGRAM 4 OF 9)
VIO/WHT WIRE
Go to component -> Power distribution circuit (1 of 9) -> EXCEPT HYBRID
Wiring diagram except hybrid (4 of 4)
Go to component -> Rear axle steering circuit -> EXCEPT HYBRID
