Porsche Cayenne Turbo III (2017-2023) elect ignition lock sw 4 Wiring diagrams
This page contains all the electrical diagrams for the component. elect ignition lock sw 4, in which he is found in the car Porsche Cayenne Turbo III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram elect ignition lock sw 4 (1 of 2)
BLU/YEL WIRE
BRN WIRE
CAN COMFORT HI
CAN COMFORT LO
CENTER CONSOLE FRONT CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
ELECT IGNITION LOCK SW 1
ELECT IGNITION LOCK SW 2
ELECT IGNITION LOCK SW 3
ELECT IGNITION LOCK SW 4
ELECTRIC TRAILER BRAKES POTENTIOMETER
ELECTRONIC IGNITION LOCK
FROM FUSE CARRIER 9 (DIAGRAM 7 OF 9)
FROM FUSE HOLDER H (DIAGRAM 7 OF 9)
FUSE 1
FUSE 2
FUSE CARRIER 8
FUSE HOLDER Y
FUSE HOLDER Z
GAS SUSPENSION COMPRESSOR
GRN WIRE
GRY/BLU WIRE
GRY/RED WIRE
HAZARD WARNING LIGHT SWITCH
HEATED REAR WINDOW RELAY
N/A
O/T RLY F PLUG SOCKETS
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT SEAT ADJUSTMENT CIRCUIT BREAKER
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4
TERM 30
TERM 31
TERM 58 D
USB CHARGING SOCKET 1
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Power distribution circuit (9 of 9) -> ELECT IGNITION LOCK SW 4
Wiring diagram elect ignition lock sw 4 (2 of 2)
ALTERNATOR
AUTOMATIC GEARBOX CONTROL UNIT
BATTERY
BATTERY ISOLATION UNIT
BATTERY MONITOR CONTROL UNIT
BLK WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRN WIRE
CAN COMFORT HI
CAN COMFORT LO
CAN DRIVE 1 HIGH
CAN DRIVE 1 LOW
COMPUTER DATA LINES SYSTEM
ELECT IGNITION LOCK SW 1
ELECT IGNITION LOCK SW 2
ELECT IGNITION LOCK SW 3
ELECT IGNITION LOCK SW 4
ENGINE/MOTOR CONTROL UNIT
FRONT FUSE BOX
FUSE 1
FUSE 11
FUSE 14
FUSE 5
FUSE CARRIER 2
FUSE CARRIER 5
FUSE HOLDER B
FUSE HOLDER D
FUSE HOLDER J
GRN WIRE
GRN/WHT WIRE
GRY/RED WIRE
HAZARD WARNING LIGHT SWITCH
HOT AT ALL TIMES
IGNITION, LIGHT BUTTON MODULE
LIN 1
N/A
NCA WIRE
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
REAR FUSE BOX
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY A STARTER MOTOR RELAY
RELAY B
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4
START REL
STARTER
STARTER RLY 1
STARTER RLY 2
TERM 30
TERM 30 1
TERM 31
TERM 50
WHT/GRY WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Starting circuit -> ELECT IGNITION LOCK SW 4
