Porsche Cayenne Turbo III (2017-2023) coolant pump for low- temperature circuit 2 Wiring diagrams
This page contains all the electrical diagrams for the component. coolant pump for low- temperature circuit 2, in which he is found in the car Porsche Cayenne Turbo III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram coolant pump for low- temperature circuit 2 (1 of 2)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE CRUISE CONTROL UNIT
AIR CONDITIONING SYSTEM PRESSURE SWITCH
BLU WIRE
BRN WIRE
BRN/BLU WIRE
CONNECTION (CONVENIENCE CAN BUS, LOW), IN REAR ARMREST WIRING HARNESS
CONNECTION (LF), IN COMMUNICATION WIRING HARNESS
CONNECTION 1, IN DRIVER SEAT BACKREST WIRING HARNESS
CONNECTION 2 (TELEPHONE), IN MAIN WIRING HARNESS
CONNECTION 2, IN WIRING HARNESS FOR ROOF OPERATION
CONNECTION 3, IN WIRING HARNESS FOR ROOF OPERATION
CONTINUED COOLANT CIRCULATION PUMP
COOLANT PUMP FOR HIGH- VOLTAGE BATTERY
COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
ELECTRICAL AIR CONDITIONER COMPRESSOR
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE/MOTOR CONTROL UNIT
FRONT LEFT HEADLIGHT
GEARBOX OIL COOLING PUMP
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
IGNITION COIL 7 (W/ OUTPUT STAGE)
IGNITION COIL 8 (W/ OUTPUT STAGE)
LEFT BONNET CONTACT SWITCH
LEFT CHARGE- AIR COOLER
LEFT FRONT RADAR SENSOR CONTROL UNIT FOR OBJECT DETECTION
RIGHT FRONT RADAR SENSOR CONTROL UNIT FOR OBJECT DETECTION
TREBLE HORN
TURBO CHARGER
Go to component -> Ground distribution circuit (1 of 6) -> COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
Wiring diagram coolant pump for low- temperature circuit 2 (2 of 2)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE SUSPENSION CONTROL UNIT
ALL-WHEEL DRIVE CONTROL UNIT
ANTI-ROLL BAR CONTROL UNIT
AUTOMATIC GEARBOX CONTROL UNIT
BRAKE LIGHT SWITCH
BRN WIRE
CLUTCH ACTUATOR
CONNECTION 1, IN MAIN WIRING HARNESS
COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
DRIVER ASSIST SYSTEMS CONTROL UNIT
EARTH CONNECTION, ON FUEL TANK FILLER NECK
ENGINE SOUND GENERATOR CONTROL UNIT 2
EXHAUST FLAP CONTROL UNIT
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER SIDE LIGHT FOR SILL PANEL MOULDING BACKGROUND LIGHTING
FUEL DELIVERY UNIT
FUEL PUMP CONTROL UNIT
GAS SUSPENSION COMPRESSOR
GEARBOX AUXILIARY HYDRAULIC PUMP
HEATED WINDSCREEM CONTROL UNIT
HIGH VOLTAGE BATTERY 1
MANUAL
POWER, CONTROL ELECTRONICS FOR ELECTRIC DRIVE
REFRIGERANT EXPANSION VALVE 2
RIGHT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT REAR SEAT HEATING CONTROL UNIT
WHT WIRE
Go to component -> Ground distribution circuit (3 of 6) -> COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
