Porsche Cayenne Turbo III (2017-2023) connection 2, in wiring harness for roof operation Wiring diagram
This page shows the only wiring diagram for the component.connection 2, in wiring harness for roof operation, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram connection 2, in wiring harness for roof operation (1 of 1)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE CRUISE CONTROL UNIT
AIR CONDITIONING SYSTEM PRESSURE SWITCH
BLU WIRE
BRN WIRE
BRN/BLU WIRE
CONNECTION (CONVENIENCE CAN BUS, LOW), IN REAR ARMREST WIRING HARNESS
CONNECTION (LF), IN COMMUNICATION WIRING HARNESS
CONNECTION 1, IN DRIVER SEAT BACKREST WIRING HARNESS
CONNECTION 2 (TELEPHONE), IN MAIN WIRING HARNESS
CONNECTION 2, IN WIRING HARNESS FOR ROOF OPERATION
CONNECTION 3, IN WIRING HARNESS FOR ROOF OPERATION
CONTINUED COOLANT CIRCULATION PUMP
COOLANT PUMP FOR HIGH- VOLTAGE BATTERY
COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
ELECTRICAL AIR CONDITIONER COMPRESSOR
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE/MOTOR CONTROL UNIT
FRONT LEFT HEADLIGHT
GEARBOX OIL COOLING PUMP
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
IGNITION COIL 7 (W/ OUTPUT STAGE)
IGNITION COIL 8 (W/ OUTPUT STAGE)
LEFT BONNET CONTACT SWITCH
LEFT CHARGE- AIR COOLER
LEFT FRONT RADAR SENSOR CONTROL UNIT FOR OBJECT DETECTION
RIGHT FRONT RADAR SENSOR CONTROL UNIT FOR OBJECT DETECTION
TREBLE HORN
TURBO CHARGER
Go to component -> Ground distribution circuit (1 of 6) -> CONNECTION 2, IN WIRING HARNESS FOR ROOF OPERATION
