Porsche Cayenne Turbo III (2017-2023) conn in rear Wiring diagram
This page shows the only wiring diagram for the component.conn in rear, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram conn in rear (1 of 1)
BRN WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
COMPUTER DATA LINES SYSTEM
CONN IN REAR
FUSE 14
FUSE HOLDER J
GRN WIRE
GROUND
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT REAR FOOTWELL LIGHT
LIN INPUT
N/A
NEGATIVE
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
POSITIVE
REAR FUSE BOX
RED/GRN WIRE
RED/WHT WIRE
RIGHT REAR FOOTWELL LIGHT
STORAGE COMPARTMENT ILLUMINATION BULB
STORAGE COMPARTMENT ILLUMINATION SWITCH
TERM 30
TERM 30 1
TERM 31
VIO/WHT WIRE
WIRING HARNESS)
YEL/RED WIRE
Go to component -> Interior lights circuit (3 of 8) -> CONN IN REAR
