Porsche Cayenne Turbo III (2017-2023) center console front cigarette lighter Wiring diagram
This page shows the only wiring diagram for the component.center console front cigarette lighter, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center console front cigarette lighter (1 of 1)
BLU/YEL WIRE
BRN WIRE
CAN COMFORT HI
CAN COMFORT LO
CENTER CONSOLE FRONT CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
ELECT IGNITION LOCK SW 1
ELECT IGNITION LOCK SW 2
ELECT IGNITION LOCK SW 3
ELECT IGNITION LOCK SW 4
ELECTRIC TRAILER BRAKES POTENTIOMETER
ELECTRONIC IGNITION LOCK
FROM FUSE CARRIER 9 (DIAGRAM 7 OF 9)
FROM FUSE HOLDER H (DIAGRAM 7 OF 9)
FUSE 1
FUSE 2
FUSE CARRIER 8
FUSE HOLDER Y
FUSE HOLDER Z
GAS SUSPENSION COMPRESSOR
GRN WIRE
GRY/BLU WIRE
GRY/RED WIRE
HAZARD WARNING LIGHT SWITCH
HEATED REAR WINDOW RELAY
N/A
O/T RLY F PLUG SOCKETS
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT SEAT ADJUSTMENT CIRCUIT BREAKER
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4
TERM 30
TERM 31
TERM 58 D
USB CHARGING SOCKET 1
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Power distribution circuit (9 of 9) -> CENTER CONSOLE FRONT CIGARETTE LIGHTER
