Porsche Cayenne Turbo III (2017-2023) brake light switch term 87 Wiring diagram
This page shows the only wiring diagram for the component.brake light switch term 87, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake light switch term 87 (1 of 1)
BLK/RED WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRAKE LIGHT SWITCH TERM 87
BRN WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
CAN INFO HIGH
CAN INFO LOW
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
FRONT FUSE BOX
FUSE 4
FUSE 5
FUSE HOLDER A
FUSE HOLDER E
GRN WIRE
HOT AT ALL TIMES
N/A
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
RED WIRE
SELECTOR LEVER SENSORS CONTROL UNIT
TERM 30
TERM 31
VIO/RED WIRE
Go to component -> Shift interlock circuit -> BRAKE LIGHT SWITCH TERM 87
