Porsche Cayenne Turbo III (2017-2023) battery charge selector buttons module Wiring diagrams
This page contains all the electrical diagrams for the component. battery charge selector buttons module, in which he is found in the car Porsche Cayenne Turbo III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram battery charge selector buttons module (1 of 2)
AIR CONDITIONING
AIR CONDITIONING SYSTEM
BATTERY CHARGE SELECTOR BUTTONS MODULE
BATTERY CHARGER (TYPE 1)
BATTERY CHARGER (TYPE 2)
BLK WIRE
BLK/BLU WIRE
BLU LED 1 WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CAN DRIVER HIGH
CAN DRIVER LOW
CHARGE-NOW
CHARGING BUTTON
COMPUTER DATA LINES SYSTEM
CONTROL PILOT (CP)
COVER LOCK 1+
CTRL PILOT 1
DIAGNOSIS
ELECTRICAL AIR CONDITIONER COMPRESSOR
EQUALIZATION
ERDE-LEITER
FUNCTION IND
GND, BODY
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GROUND LINE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
HIGH VOLTAGE BATTERY CHARGING UNIT 1
HIGH-VOLTAGE BATTERY CHARGING SOCKET 1
HIGH-VOLTAGE CHARGING FLAP LOCK 1 ACTUATOR
HIGH-VOLTAGE HEATER (PTC)
LADEST 1 GND
LED GND 1
LED GREEN
LED GREEN 1
LED RED WIRE
LED ROT 1
LI-LEITER
LI-LEITRE
LOCKING,
NULL-LEITER
ORG/BRN WIRE
PILOTLINE IN
PILOTLINE OUT
POTENTIAL
PROXIMITY (PP)
PROXIMITY 1
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SEARCH LIGHTING
SHIELD
SYSTEM
TAN WIRE
TEMP SENS
TEMP SENS GND
TERM 30
TERM 31
TIMER CHARGE
UNLOCK
VER LADEST 1 +
VIO WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YELLOW LED
Go to component -> Wiring diagram engine performance 3.0l turbo hybrid, hybrid system circuit (3 of 5) -> BATTERY CHARGE SELECTOR BUTTONS MODULE
