Porsche Cayenne S III (2017-2023) Ground distribution circuit
Ground distribution circuit (1 of 8)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE CRUISE CONTROL UNIT
AIR CONDITIONING SYSTEM PRESSURE SWITCH
BLU WIRE
BRN WIRE
BRN/BLU WIRE
CIRCULATION PUMP
CONTINUED COOLANT CIRCULATION PUMP
COOLANT SHORTAGE INDICATOR SENDER 2
ELECTRICAL AIR CONDITIONER COMPRESSOR
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE/MOTOR CONTROL UNIT
FRONT LEFT HEADLIGHT
GEARBOX OIL COOLING PUMP
HIGH VOLTAGE BATTERY COOLANT PUMP
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
IGNITION COIL 7 (W/ OUTPUT STAGE)
IGNITION COIL 8 (W/ OUTPUT STAGE)
LEFT BONNET CONTACT SWITCH
LEFT CHARGE- AIR COOLER
LEFT FRONT OBJECT DETECTION RADAR SENSOR CONTROL UNIT
LEFT FRONT TURN SIGNAL, SIDE LIGHT
REFRIGERANT EXPANSION VALVE 2
RIGHT ELECTRO-HYDRAULIC ENGINE MOUNTING SOLENOID VALVE
RIGHT FRONT OBJECT DETECTION RADAR SENSOR CONTROL UNIT
TREBLE HORN
TURBO CHARGER
Ground distribution circuit (2 of 8)
ALARM HORN
AUXILIARY HEATER CONTROL UNIT
AUXILIARY PUMP FOR HEATING
BACKUP HORN SIREN
BASS HORN
BRAKE LIGHT SWITCH
BRAKE SERVO CONTROL UNIT
BRN WIRE
CIRCULATION PUMP 2
COOLANT CIRCUIT SOLENOID
DIAGNOSTIC CONNECTION
DRIVER DOOR CONTROL UNIT
DRIVER SIDE CENTRAL LOCKING LOCK UNIT
ELECTRIC TRAILER BRAKES POTENTIOMETER
ELECTRICAL AIR CONDITIONER COMPRESSOR
ELECTRO-HYDRAULIC ENGINE MOUNTING CONTROL UNIT
HIGH VOLTAGE BATTERY PRE- HEATING MIXING VALVE 2
HIGH-VOLTAGE HEATER (PTC)
LEFT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
LEFT PEDESTRIAN PROTECTION TRIGGER 1
NIGHT VISION SYSTEM CAMERA WASHER PUMP
ONBOARD SUPPLY CONTROL UNIT
RADIATOR BLIND CONTROL MOTOR
RADIATOR BLIND CONTROL MOTOR 3
RADIATOR BLIND CONTROL MOTOR 5
RADIATOR FAN
REFRIGERANT CIRCULATION SOLENOID VALVE
RIGHT BONNET CONTACT SWITCH 2
RIGHT FRONT HEADLIGHT
RIGHT REAR TRIGGER 2 FOR PEDESTRIAN PROTECTION
SECONDARY AIR PUMP MOTOR
SOLENOID VALVE 2
SOLENOID VALVE 3
SOLENOID VALVE 4
STRUCTURE-BORNE SOUND CONTROL UNIT
TERMINAL 15 VOLTAGE SUPPLY RELAY
THERMAL MANAGEMENT CONTROL UNIT
WINDSCREEN WIPER
Ground distribution circuit (3 of 8)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE SUSPENSION CONTROL UNIT
ALL-WHEEL DRIVE CONTROL UNIT
AUTOMATIC GEARBOX CONTROL UNIT
BRAKE LIGHT SWITCH
BRN WIRE
CLUTCH ACTUATOR
COOLANT PUMP LOW TEMPERATURE CIRCUIT 2
DRIVER ASSIST SYSTEMS CONTROL UNIT
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
ENGINE SOUND GENERATOR CONTROL UNIT 2
EXHAUST FLAP CONTROL UNIT
FRONT ANTI-ROLL BAR CONTROL UNIT
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER SIDE LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
FUEL DELIVERY UNIT
FUEL PUMP CONTROL UNIT
GAS SUSPENSION COMPRESSOR
GEARBOX AUXILIARY HYDRAULIC PUMP
GEARBOX OIL COOLING PUMP
HEATED WINDSCREEN CONTROL UNIT
RIGHT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT REAR SEAT HEATING CONTROL UNIT
WHT WIRE
Ground distribution circuit (4 of 8)
ACCELERATOR PEDAL MODULE
BLK WIRE
BRN WIRE
DATA BUS DIAGNOSTIC INTERFACE
DRIVER ASSIST SYSTEMS CONTROL UNIT
DRIVER SIDE AIR BAG IGNITER
DRIVER SIDE LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
FRONT PASSENGER SIDE AIR BAG IGNITER
HEATED WINDSCREEN CONTROL UNIT
LEFT FRONT HEATED SEAT CUSHION
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT BELT
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT EXTENSION HEATER ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT REAR CENTRAL LOCKING LOCK UNIT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR EXTERIOR DOOR HANDLE CONTACT SENSOR
LEFT REAR FOOTWELL LIGHT
LEFT REAR SMART DISPLAY CONTROL UNIT
LEFT SIDE REAR LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
NIGHT VISION SYSTEM CONTROL UNIT
RIGHT FRONT HEATED SEAT CUSHION
RIGHT FRONT SEAT BACKREST FAN 1
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT CUSHION FAN 1
RIGHT FRONT SEAT EXTENSION HEATER ELEMENT
RIGHT FRONT SEAT HEATED BACKREST
RIGHT REAR CENTRAL LOCKING LOCK UNIT
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR DOOR UNIT LIGHTING
RIGHT REAR EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT REAR FOOTWELL LIGHT
RIGHT REAR SMART DISPLAY CONTROL UNIT
RIGHT REAR VENT ILLUMINATION BULB
RIGHT SIDE REAR LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
SEAT OCCUPIED RECOGNITION CONTROL UNIT
TELEPHONE, TELEMATICS CONTROL UNIT
W/ TENSIONER HEIGHT ADJUSTMENT
W/O ADDITIONAL LIGHTS W/ ADDITIONAL LIGHTS
WHT WIRE
Ground distribution circuit (5 of 8)
ADJUSTABLE REAR SPOILER CONTROL UNIT
ADJUSTABLE REAR SPOILER MOTOR
AIR CONDITIONING SYSTEM CONTROL UNIT
ASHTRAY ILLUMINATION BULB
AUXILIARY HEATER REMOTE CONTROL RECEIVER
BLUETOOTH MOBILE PHONE COUPLING AERIAL
BRN WIRE
CENTER CONSOLE REAR STORAGE COMPARTMENT ILLUMINATION BULB
CIGARETTE LIGHTER
DIGITAL SOUND PACKAGE AMPLIFIER
DRIVER SIDE REAR AIR BAG IGNITER
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
HIGH VOLTAGE BATTERY CHARGING UNIT 1
IN LUGGAGE COMPT)
LEFT DRINKS HOLDER ILLUMINATION BULB
LEFT REAR SEAT BACKREST FAN 1
LEFT REAR SEAT CUSHION FAN 1
LEFT REAR SEAT HEATED BACKREST
LEFT REAR SEAT HEATED BENCH CUSHION
MOBILE TELEPHONE AERIAL AMPLIFIER
PASSENGER SIDE REAR AIR BAG IGNITER
RADIO CONTROLLED PARKING CONTROL UNIT
REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT
REAR CENTER ASHTRAY ILLUMINATION BULB
REAR FRESH AIR BLOWER
RIGHT LUGGAGE COMPARTMENT LIGHT
RIGHT REAR SEAT BACKREST FAN 1
RIGHT REAR SEAT CUSHION FAN 1
RIGHT REAR SEAT HEATED BACKREST
RIGHT REAR SEAT HEATED BENCH CUSHION
RIGHT TAIL LIGHT CLUSTER
SELECTOR LEVER SENSORS CONTROL UNIT
STORAGE COMPARTMENT ILLUMINATION SWITCH
SUNROOF ROLLER BLIND CONTROL UNIT
TANK FILLER FLAP LOCKING MOTOR
USB CHARGING SOCKET 1
VEHICLE LOCATION SYSTEM AERIAL 3 SHIELD
VEHICLE LOCATION SYSTEM CONTROL UNIT
VEHICLE LOCATION SYSTEM CONTROL UNIT SHIELD
Ground distribution circuit (6 of 8)
AIR HUMIDITY RAIN, LIGHT SENSOR
ANTI-ROLL BAR CONTROL UNIT 2
AXLE DIFFERENTIAL LOCK CONTROL UNIT
BRN WIRE
BRN/VIO WIRE
CLIMATRONIC OPERATING UNIT WIRING HARNESS
CLIMATRONIC WIRING HARNESS, RADIATOR FAN
ENGINE SOUND GENERATOR CONTROL UNIT
EXHAUST FLAP CONTROL UNIT
EXHAUST FLAP CONTROL UNIT 2
FRONT ANTI-ROLL BAR CONTROL UNIT
FRONT ROOF MODULE
FUSE CARRIER 5
GARAGE DOOR OPERATION CONTROL UNIT
HEATED REAR WINDOW RELAY
HIGH VOLTAGE BATTERY CHARGING UNIT 1
INTERIOR MIRROR
LANE CHANGE ASSIST CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT 2
LEFT "C" PILLAR)
LEFT EXHAUST FLAP CONTROL UNIT 2
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT REAR BRAKE PAD WEAR SENDER
LEFT REAR SEAT HEATING CONTROL
LEFT TAIL LIGHT CLUSTER
ONBOARD SUPPLY CONTROL UNIT 2
OPENING EXHAUST FLAP 2 CONTROL UNIT 2
PTC HEATER ELEMENT 1
REAR ANTI-ROLL BAR CONTROL UNIT 2
REAR LID POWER OPENING SENDER
RELAY CARRIER 6
RIGHT EXHAUST FLAP CONTROL UNIT 2
SEAT VENTILATION RELAY
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
SUBWOOFER
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
TRAILER DETECTOR CONTROL UNIT
VIO/BRN WIRE
YEL WIRE
Ground distribution circuit (7 of 8)
AIR HUMIDITY
BLK WIRE
BRN WIRE
CENTER TAILLIGHT CLUSTER
CHIP CARD READER
FRONT CAMERA DRIVER ASSIST SYSTEM
FRONT PASSENGER AIR BAG UNIT
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
FRONT ROOF MODULE
HIGH-LEVEL BRAKE LIGHT BULB
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
IGNITION COIL 7 (W/ OUTPUT STAGE)
IGNITION COIL 8 (W/ OUTPUT STAGE)
INTERIOR MIRROR
LEFT DRINKS HOLDER ILLUMINATION BULB
LEFT FRONT FOOTWELL LIGHT
LEFT NUMBER PLATE LIGHT
LEFT VENT ILLUMINATION BULB DASH PANEL
REAR LID CLOSURE BUTTON
REAR LID LIGHT
REAR LID LIGHT 2
REAR LID LOCK CYLINDER RELEASE BUTTON
REAR LID LOCK UNIT
REAR LID POWER LATCHING
REAR LID POWER OPENING CONTROL UNIT
REAR WHEEL STEERING CONTROL UNIT
REAR WINDOW WIPER MOTOR
REVERSING CAMERA SYSTEM CONTROL UNIT
RIGHT NUMBER PLATE LIGHT
SERVOTRONIC CONTROL UNIT
SUNROOF ROLLER BLIND CONTROL UNIT
W/O ADDITIONAL LIGHTS W/ ADDITIONAL LIGHTS
Ground distribution circuit (8 of 8)
ACCELERATOR PEDAL MODULE
AIR CONDITIONING SYSTEM CONTROL UNIT
BRN WIRE
CENTER VENT
DASH PANEL INSERT
DRIVER SIDE KNEE AIR BAG IGNITER
ELECTRONIC IGNITION LOCK
FRESH AIR BLOWER
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
GLOVE COMPARTMENT LIGHT SWITCH
HEAD-UP DISPLAY CONTROL UNIT
IONISER 1
KNEE AIR BAG IGNITER DRIVER SIDE
LEFT FRONT FOOTWELL LIGHT
LEFT VENT ILLUMINATION BULB DASH PANEL
MULTIMEDIA SYSTEM
MULTIMEDIA SYSTEM OPERATING UNIT
MULTIMEDIA SYSTEM OPERATING UNIT 2
REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT
REAR CENTER VENT
RIGHT FRONT FOOTWELL LIGHT
ROTARY LIGHT SWITCH
STEERING COLUMN CONTROL UNIT
STEERING COLUMN ELECTRICALLY ADJUSTABLE CONTROL UNIT
STEERING COLUMN ELECTRONICS CONTROL UNIT
STEERING COLUMN LOCK CONTROL ELEMENT
STORAGE COMPARTMENT ILLUMINATION SWITCH
W/O ADDITIONAL LIGHTS W/ ADDITIONAL LIGHTS
