Exterior lamps circuit for Porsche Cayenne S III (2017-2023)

BACKUP BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/YEL WIRE BLU/BLK WIRE BODY GND BRAKE LIGHT SWITCH BRAKE SERVO CONTROL UNIT BRN WIRE CAN COMFORT HIGH CAN COMFORT LOW CAN HIGH CAN LOW CENTER TAIL LIGHT CLUSTER CIRCUIT COMPUTER DATA LINES SYSTEM ENGINE/ MOTOR CONTROL UNIT EXCEPT HYBRID FRONT FUSE BOX FUSE 15 FUSE 16 FUSE 5 FUSE HOLDER A FUSE HOLDER D GRN WIRE GRN/BLK WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE HIGH MOUNTED STOP LIGHT HOT W/ MAIN RELAY ENERGIZED HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED LAMPS) LEFT BRAKE LIGHT LEFT FRONT HEADLIGHT LEFT FRONT TURN SIGNAL, SIDE LIGHT LEFT NUMBER PLATE LIGHT LEFT REAR INDICATOR LEFT REVERSE LIGHT LEFT SIDE MARKER LIGHT LEFT TAIL LIGHT LEFT TAIL LIGHT CLUSTER LEFT TAIL/BRAKE LIGHT 1 LEFT TAIL/BRAKE LIGHT 2 LEFT TAIL/BRAKE LIGHT 3 LEFT TAIL/BRAKE LIGHT 4 LEFT TURN SIGNAL MARKER LIGHT N/A NUMBER PLATE LIGHT + ONBOARD SUPPLY CONTROL UNIT 2 ORG/BRN WIRE RIGHT BRAKE LIGHT RIGHT NUMBER PLATE LIGHT RIGHT REAR INDICATOR RIGHT REVERSE LIGHT RIGHT SIDE MARKER LIGHT RIGHT TAIL LIGHT RIGHT TAIL/BRAKE LIGHT 1 RIGHT TAIL/BRAKE LIGHT 2 RIGHT TAIL/BRAKE LIGHT 3 RIGHT TAIL/BRAKE LIGHT 4 RIGHT TURN SIGNAL TERM 15 TERM 30 TERM 30 1 TERM 31 TERM 58 TERM 87 TURN SIGNAL VIO/RED WIRE WHT/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

AUTOMATIC GEARBOX WIRING HARNESS CONNECTION (CCS) BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLU/VIO WIRE BRAKE LIGHT SWITCH BRN WIRE BRN/BLU WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DASHBOARD FUSE BOX ELECTRONIC IGNITION LOCK FUSE 11 FUSE 14 FUSE HOLDER A FUSE HOLDER J GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE HAZ WARN LIGHT BUTTON HAZARD WARNING LIGHT SWITCH HIGH-LEVEL BRAKE LIGHT BULB HOT AT ALL TIMES LEFT BRAKE/DIR INDICATOR LEFT TURN SIGNAL LF PARKING LIGHT LIN LIN 1 MARKER LIGHT N/A ONBOARD SUPPLY CONTROL UNIT ORG/BRN WIRE REAR FUSE BOX RED/YEL WIRE RF PARKING LIGHT RIGHT BRAKE LIGHT RIGHT BRAKE/DIR INDICATOR RIGHT FRONT HEADLIGHT RIGHT FRONT TURN SIGNAL, SIDE LIGHT RIGHT REAR DIR INDICATOR RIGHT TAIL LIGHT RIGHT TAIL LIGHT CLUSTER RIGHT TURN SIGNAL ROTARY LIGHT SWITCH SENSOR GROUND TAILLIGHT TERM 15 TERM 30 TERM 31 TRAILER DETECTOR CONTROL UNIT TURN SIGNAL VIO/WHT WIRE WHT/GRY WIRE WHT/VIO WIRE YEL/RED WIRE
