Porsche Cayenne S III (2017-2023) sub gateway interface control unit Wiring diagram

BRN WIRE CAN CONNECT HIGH CAN CONNECT LOW CAN HIGH CAN HYBRID HIGH CAN HYBRID LOW CAN L CAN LOW CAN SUB H CAN SUB L DATA BUS DIAGNOSTIC INTERFACE DIAGNOSTIC CONNECTION ELECTRIC DRIVE POWER, CONTROL ELECTRONICS ETHERNET FLEXRAY BRANCH 1 BM FLEXRAY BRANCH 1 BP FRONT FUSE BOX FUSE 1 FUSE 12 FUSE HOLDER D FUSE HOLDER E GRN WIRE GRY/RED WIRE GRY/VIO WIRE HIGH VOLTAGE BATTERY 1 HIGH VOLTAGE BATTERY CHARGING UNIT 1 HOT AT ALL TIMES HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED N/A ORG/BLK WIRE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE RED WIRE RED/BLU WIRE SUB GATEWAY INTERFACE CONTROL UNIT T CAN HIGH T CAN LOW TAN WIRE TELEMATICS INTERFACE CONTROL UNIT TELEPHONE, TELEMATICS CONTROL UNIT THERMAL MANAGEMENT CONTROL UNIT VEHICLE LOCATION SYSTEM CONTROL UNIT
