Porsche Cayenne S III (2017-2023) storage compartment illumination switch Wiring diagrams

ADJUSTABLE REAR SPOILER CONTROL UNIT ADJUSTABLE REAR SPOILER MOTOR AIR CONDITIONING SYSTEM CONTROL UNIT ASHTRAY ILLUMINATION BULB AUXILIARY HEATER REMOTE CONTROL RECEIVER BLUETOOTH MOBILE PHONE COUPLING AERIAL BRN WIRE CENTER CONSOLE REAR STORAGE COMPARTMENT ILLUMINATION BULB CIGARETTE LIGHTER DIGITAL SOUND PACKAGE AMPLIFIER DRIVER SIDE REAR AIR BAG IGNITER ELECTRO- MECHANICAL PARKING BRAKE BUTTON HIGH VOLTAGE BATTERY CHARGING UNIT 1 IN LUGGAGE COMPT) LEFT DRINKS HOLDER ILLUMINATION BULB LEFT REAR SEAT BACKREST FAN 1 LEFT REAR SEAT CUSHION FAN 1 LEFT REAR SEAT HEATED BACKREST LEFT REAR SEAT HEATED BENCH CUSHION MOBILE TELEPHONE AERIAL AMPLIFIER PASSENGER SIDE REAR AIR BAG IGNITER RADIO CONTROLLED PARKING CONTROL UNIT REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT REAR CENTER ASHTRAY ILLUMINATION BULB REAR FRESH AIR BLOWER RIGHT LUGGAGE COMPARTMENT LIGHT RIGHT REAR SEAT BACKREST FAN 1 RIGHT REAR SEAT CUSHION FAN 1 RIGHT REAR SEAT HEATED BACKREST RIGHT REAR SEAT HEATED BENCH CUSHION RIGHT TAIL LIGHT CLUSTER SELECTOR LEVER SENSORS CONTROL UNIT STORAGE COMPARTMENT ILLUMINATION SWITCH SUNROOF ROLLER BLIND CONTROL UNIT TANK FILLER FLAP LOCKING MOTOR USB CHARGING SOCKET 1 VEHICLE LOCATION SYSTEM AERIAL 3 SHIELD VEHICLE LOCATION SYSTEM CONTROL UNIT VEHICLE LOCATION SYSTEM CONTROL UNIT SHIELD

ACCELERATOR PEDAL MODULE AIR CONDITIONING SYSTEM CONTROL UNIT BRN WIRE CENTER VENT DASH PANEL INSERT DRIVER SIDE KNEE AIR BAG IGNITER ELECTRONIC IGNITION LOCK FRESH AIR BLOWER FRONT PASSENGER SIDE KNEE AIR BAG IGNITER GLOVE COMPARTMENT LIGHT SWITCH HEAD-UP DISPLAY CONTROL UNIT IONISER 1 KNEE AIR BAG IGNITER DRIVER SIDE LEFT FRONT FOOTWELL LIGHT LEFT VENT ILLUMINATION BULB DASH PANEL MULTIMEDIA SYSTEM MULTIMEDIA SYSTEM OPERATING UNIT MULTIMEDIA SYSTEM OPERATING UNIT 2 REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT REAR CENTER VENT RIGHT FRONT FOOTWELL LIGHT ROTARY LIGHT SWITCH STEERING COLUMN CONTROL UNIT STEERING COLUMN ELECTRICALLY ADJUSTABLE CONTROL UNIT STEERING COLUMN ELECTRONICS CONTROL UNIT STEERING COLUMN LOCK CONTROL ELEMENT STORAGE COMPARTMENT ILLUMINATION SWITCH W/O ADDITIONAL LIGHTS W/ ADDITIONAL LIGHTS

BRN WIRE CAN COMFORT HIGH CAN COMFORT LOW COMPUTER DATA LINES SYSTEM CONN IN REAR FUSE 14 FUSE HOLDER J GRN WIRE GROUND GRY/BLU WIRE HOT AT ALL TIMES LEFT REAR FOOTWELL LIGHT LIN INPUT N/A NEGATIVE ONBOARD SUPPLY CONTROL UNIT 2 ORG/BRN WIRE POSITIVE REAR FUSE BOX RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR FOOTWELL LIGHT STORAGE COMPARTMENT ILLUMINATION BULB STORAGE COMPARTMENT ILLUMINATION SWITCH TERM 30 TERM 30 1 TERM 31 VIO/RED WIRE VIO/WHT WIRE WIRING HARNESS) YEL/RED WIRE
