Porsche Cayenne S III (2017-2023) sensor ground 2 Wiring diagram
This page shows the only wiring diagram for the component.sensor ground 2, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensor ground 2 (1 of 1)
ACTUATORS/SENSORS SPLY
AIR CONDITIONING SYSTEM CONTROL UNIT (CENTER OF DASH)
AIR CONDITIONING SYSTEM PRESSURE SWITCH
AIR QUALITY SENSOR
AIR RECIRCULATION FLAP CONTROL MOTOR
ANALOGUE 1
ANALOGUE 2
ANALOGUE 3
AUTOMATIC HEATER CONTROL INTERIOR SENSOR
BLK/BRN WIRE
BRN WIRE
BRN/BLU WIRE
EVAPORATOR TEMPERATURE
FRESH AIR FLAP CONTROL MOTOR
FRONT FUSE BOX
FUSE 1
FUSE HOLDER D
GROUND ACTR
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY
LEFT POTENTIOMETER SIG
LF FOOTWELL BLOWER SENS
LIN
LIN 1
LIN INPUT
LIN OUTPUT
N/A
REAR AIR QUANTITY CONTROL MOTOR
RED WIRE
RED/BLU WIRE
RH FOOTWELL BLOWER SENS
RIGHT FOOTWELL FLAP CONTROL MOTOR
RIGHT REAR AIR QUANTITY FLAP CONTROL MOTOR
RIGHT TEMPERATURE FLAP CONTROL MOTOR
SENS 1
SENS 2
SENS 3
SENSOR GROUND 1
SENSOR GROUND 2
TERM 15
TERM 30
TERM 31
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component: -> Automatic a/c circuit (4 of 11) -> SENSOR GROUND 2
