Porsche Cayenne S III (2017-2023) seat heating element Wiring diagram
This page shows the only wiring diagram for the component.seat heating element, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat heating element (1 of 1)
AIR CONDITIONING SYSTEM CONTROL UNIT
BACKREST HEATING ELEMENT
BACKREST TEMP SENDER
BLK/VIO WIRE
BRN WIRE
CODING PIN 1
CODING PIN 3
COMPUTER DATA LINES SYSTEM
FRONT FUSE BOX
FUSE 12
FUSE 8
FUSE HOLDER D
FUSE HOLDER G
GROUND
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
LEFT "C" PILLAR)
LEFT REAR SEAT BACKREST FAN 1
LEFT REAR SEAT CUSHION FAN 1
LEFT REAR SEAT HEATED BACKREST
LEFT REAR SEAT HEATED BENCH SEAT CUSHION
LEFT REAR SEAT HEATING CONTROL UNIT
LIN
LIN 5
N/A
PIN CODING 1
REAR FUSE BOX
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT REAR SEAT BACKREST FAN 1
RIGHT REAR SEAT CUSHION FAN 1
RIGHT REAR SEAT HEATED BACKREST
RIGHT REAR SEAT HEATED BENCH CUSHION
RIGHT REAR SEAT HEATING CONTROL UNIT
SEAT HEATING ELEMENT
TEMPERATURE SENSOR
TERM 15
TERM 30
TERM 31
VIO/RED WIRE
VIO/WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
