Porsche Cayenne S III (2017-2023) right side rear sun blind motor Wiring diagram
This page shows the only wiring diagram for the component.right side rear sun blind motor, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right side rear sun blind motor (1 of 1)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FRONT FUSE BOX
FUSE 6
FUSE HOLDER C
GRN/YEL WIRE
HALL SENS
HALL SENSOR
HOT AT ALL TIMES
LEFT REAR DOOR CONTROL UNIT
LEFT SIDE REAR SUN BLIND MOTOR
LIN
N/A
RED/VIO WIRE
RED/YEL WIRE
RIGHT REAR DOOR CONTROL UNIT
RIGHT SIDE REAR SUN BLIND MOTOR
SUN BLIND MTR -
TERM 31
WHT WIRE
YEL/BLU WIRE
Go to component: -> Roller sun blind circuit -> RIGHT SIDE REAR SUN BLIND MOTOR
