Porsche Cayenne S III (2017-2023) right rear power latching motor Wiring diagrams

BLK/RED WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE BUTTON FOR REAR INTERIOR CENTRAL LOCK MOTOR LOCK CENTRAL LOCK MOTOR SAFE/LOCK CENTRAL LOCK MOTOR UNLOCK CENTRAL LOCK SAFE CHILD LOCK MOTOR PCL CHILD LOCK ON CLOSING AID - CONTACT SWITCH DOOR CONTACT FUNCTION LED GND, BODY GRN/RED WIRE GRY/BLU WIRE GRY/VIO WIRE INTERIOR DOOR HANDLE INTERIOR LOCKING LANE CHANGE ASSIST WARNING LAMP LEFT REAR CENTRAL LOCKING LOCK UNIT LEFT REAR CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON LEFT REAR POWER LATCHING MOTOR LIN LOCKING BUTTON LED LOCKING PAWL LOCKING PAWL RELEASE MOTOR MOTOR 1 MOTOR 2 RED/VIO WIRE RED/YEL WIRE RIGHT REAR CENTRAL LOCKING LOCK UNIT RIGHT REAR CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON RIGHT REAR POWER LATCHING MOTOR ROTARY CATCH SAFE MOTOR SWITCH VIO/BLK WIRE VIO/WHT WIRE WARNING LAMP WHT WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/RED WIRE

BLK/RED WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE BUTTON FOR REAR INTERIOR CENTRAL LOCK MOTOR LOCK CENTRAL LOCK MOTOR SAFE/LOCK CENTRAL LOCK MOTOR UNLOCK CENTRAL LOCK SAFE CHILD LOCK MOTOR PCL CHILD LOCK ON CLOSING AID - CONTACT SWITCH DOOR CONTACT FUNCTION LED GND, BODY GRN/RED WIRE GRY/BLU WIRE GRY/VIO WIRE INTERIOR DOOR HANDLE INTERIOR LOCKING LANE CHANGE ASSIST WARNING LAMP LEFT REAR CENTRAL LOCKING LOCK UNIT LEFT REAR CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON LEFT REAR POWER LATCHING MOTOR LIN LOCKING BUTTON LED LOCKING PAWL LOCKING PAWL RELEASE MOTOR MOTOR 1 MOTOR 2 RED/VIO WIRE RED/YEL WIRE RIGHT REAR CENTRAL LOCKING LOCK UNIT RIGHT REAR CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON RIGHT REAR POWER LATCHING MOTOR ROTARY CATCH SAFE MOTOR SWITCH VIO/BLK WIRE VIO/WHT WIRE WARNING LAMP WHT WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/RED WIRE
