Porsche Cayenne S III (2017-2023) red/wht Wiring diagrams
This page contains all the electrical diagrams for the component. red/wht, in which he is found in the car Porsche Cayenne S III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
red/wht wiring diagram (101 of 108)
3.0L TURBO, 2.9L TURBO, 3.0L TURBO HYBRID
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
CAN DRIVE 1 HI
CAN DRIVE 1 LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMP ENGINE OUTLET
CYLINDER CHANGE OVER COOLANT VALVE BLOCK
ENGINE COVER PANEL TEMPERATURE SENDER
ENGINE/MOTOR CONTROL UNIT
FRONT FUSE BOX
FUSE 13
FUSE 14
FUSE 3
FUSE BOXES
FUSE CARRIER 4
FUSE HOLDER A
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
HEAD BLOCK VALVE +
HOT AT ALL TIMES
LIN
N/A
PWM
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR OUTLET
RADIATOR OUTLET COOLANT TEMPERATURE SENDER
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR CYLINDER HEAD -
SIG
TEMP SENS ON CRANKCASE -
TEMP SENS ON ENGINE COVER -
TERM 30
TERM 31
TERM 87
THERMOSTAT MAP
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> 2.9l turbo, cooling fan circuit (1 of 2) -> RED/WHT WIRE
red/wht wiring diagram (102 of 108)
3.0L TURBO, 2.9L TURBO, 3.0L TURBO HYBRID
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
CAN DRIVE 1 HI
CAN DRIVE 1 LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMP ENGINE OUTLET
CYLINDER CHANGE OVER COOLANT VALVE BLOCK
ENGINE COVER PANEL TEMPERATURE SENDER
ENGINE/MOTOR CONTROL UNIT
FRONT FUSE BOX
FUSE 13
FUSE 14
FUSE 3
FUSE BOXES
FUSE CARRIER 4
FUSE HOLDER A
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
HEAD BLOCK VALVE +
HOT AT ALL TIMES
LIN
N/A
PWM
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR OUTLET
RADIATOR OUTLET COOLANT TEMPERATURE SENDER
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR CYLINDER HEAD -
SIG
TEMP SENS ON CRANKCASE -
TEMP SENS ON ENGINE COVER -
TERM 30
TERM 31
TERM 87
THERMOSTAT MAP
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> 3.0l turbo, cooling fan circuit (1 of 2) -> RED/WHT WIRE
red/wht wiring diagram (103 of 108)
3.0L TURBO, 2.9L TURBO, 3.0L TURBO HYBRID
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
CAN DRIVE 1 HI
CAN DRIVE 1 LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMP ENGINE OUTLET
CYLINDER CHANGE OVER COOLANT VALVE BLOCK
ENGINE COVER PANEL TEMPERATURE SENDER
ENGINE/MOTOR CONTROL UNIT
FRONT FUSE BOX
FUSE 13
FUSE 14
FUSE 3
FUSE BOXES
FUSE CARRIER 4
FUSE HOLDER A
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
HEAD BLOCK VALVE +
HOT AT ALL TIMES
LIN
N/A
PWM
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR OUTLET
RADIATOR OUTLET COOLANT TEMPERATURE SENDER
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR CYLINDER HEAD -
SIG
TEMP SENS ON CRANKCASE -
TEMP SENS ON ENGINE COVER -
TERM 30
TERM 31
TERM 87
THERMOSTAT MAP
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> 3.0l turbo hybrid, cooling fan circuit (1 of 2) -> RED/WHT WIRE
red/wht wiring diagram (104 of 108)
AIR CONDITIONING SYSTEM
BLK/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CAN HIGH HYBRID
CAN HYBRID HIGH
CAN HYBRID LOW
CAN LOW HYBRID
CIRCULATION PUMP
COMPUTER DATA LINES SYSTEM
COOLANT PMP RLY
COOLANT PUMP RELAY
COOLANT SHORTAGE IND
COOLANT SHORTAGE INDICATOR SENDER 2
EANABLE RADIATOR FAN 1
EANABLE RADIATOR FAN 2
ENGINE/MOTOR CONTROL UNIT
FLEXRAY 2- OUTPUT PNK FLEXRAY 2+ OUTPUT WIRE
FRONT FUSE BOX
FUSE 11
FUSE 14
FUSE 3
FUSE CARRIER 4
FUSE HOLDER B
FUSE HOLDER K
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
HIGH VOLTAGE BATTERY 1
HIGH VOLTAGE BATTERY COOLANT PUMP
HOT AT ALL TIMES
LOCK
LOW TEMPERATURE CIRCUIT COOLANT PUMP 2
N/A
ORG/BRN WIRE
POSITIVE
PWM
PWM PUMP
PWM RADIATOR FAN 1
PWM RADIATOR FAN 2
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR RELAY
REAR FUSE BOX
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 6
TAN WIRE
TERM 30
TERM 30 RELAY
TERM 87
THERMAL MANAGEMENT CONTROL UNIT
UBATT
VIO/WHT WIRE
YEL/VIO WIRE
Go to component -> 3.0l turbo hybrid, hybrid cooling fan circuit -> RED/WHT WIRE
red/wht wiring diagram (105 of 108)
3.0L TURBO, 2.9L TURBO, 3.0L TURBO HYBRID
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
CAN DRIVE 1 HI
CAN DRIVE 1 LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMP ENGINE OUTLET
CYLINDER CHANGE OVER COOLANT VALVE BLOCK
ENGINE COVER PANEL TEMPERATURE SENDER
ENGINE/MOTOR CONTROL UNIT
FRONT FUSE BOX
FUSE 13
FUSE 14
FUSE 3
FUSE BOXES
FUSE CARRIER 4
FUSE HOLDER A
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
HEAD BLOCK VALVE +
HOT AT ALL TIMES
LIN
N/A
PWM
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR OUTLET
RADIATOR OUTLET COOLANT TEMPERATURE SENDER
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR CYLINDER HEAD -
SIG
TEMP SENS ON CRANKCASE -
TEMP SENS ON ENGINE COVER -
TERM 30
TERM 31
TERM 87
THERMOSTAT MAP
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> 4.0l turbo, cooling fan circuit (1 of 2) -> RED/WHT WIRE
red/wht wiring diagram (106 of 108)
3.0L TURBO, 2.9L TURBO, 3.0L TURBO HYBRID
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
CAN DRIVE 1 HI
CAN DRIVE 1 LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMP ENGINE OUTLET
CYLINDER CHANGE OVER COOLANT VALVE BLOCK
ENGINE COVER PANEL TEMPERATURE SENDER
ENGINE/MOTOR CONTROL UNIT
FRONT FUSE BOX
FUSE 13
FUSE 14
FUSE 3
FUSE BOXES
FUSE CARRIER 4
FUSE HOLDER A
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
HEAD BLOCK VALVE +
HOT AT ALL TIMES
LIN
N/A
PWM
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR OUTLET
RADIATOR OUTLET COOLANT TEMPERATURE SENDER
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR CYLINDER HEAD -
SIG
TEMP SENS ON CRANKCASE -
TEMP SENS ON ENGINE COVER -
TERM 30
TERM 31
TERM 87
THERMOSTAT MAP
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> 4.0l turbo hybrid, cooling fan circuit (1 of 2) -> RED/WHT WIRE
red/wht wiring diagram (107 of 108)
AIR CONDITIONING SYSTEM
BLK/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CAN HIGH HYBRID
CAN HYBRID HIGH
CAN HYBRID LOW
CAN LOW HYBRID
CIRCULATION PUMP
COMPUTER DATA LINES SYSTEM
COOLANT PMP RLY
COOLANT PUMP RELAY
COOLANT SHORTAGE IND
COOLANT SHORTAGE INDICATOR SENDER 2
EANABLE RADIATOR FAN 1
EANABLE RADIATOR FAN 2
ENGINE/MOTOR CONTROL UNIT
FLEXRAY 2- OUTPUT PNK FLEXRAY 2+ OUTPUT WIRE
FRONT FUSE BOX
FUSE 11
FUSE 14
FUSE 3
FUSE CARRIER 4
FUSE HOLDER B
FUSE HOLDER K
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
HIGH VOLTAGE BATTERY 1
HIGH VOLTAGE BATTERY COOLANT PUMP
HOT AT ALL TIMES
LOCK
LOW TEMPERATURE CIRCUIT COOLANT PUMP 2
N/A
ORG/BRN WIRE
POSITIVE
PWM
PWM PUMP
PWM RADIATOR FAN 1
PWM RADIATOR FAN 2
RADIATOR FAN (BEHIND RADIATOR)
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR RELAY
REAR FUSE BOX
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 6
TAN WIRE
TERM 30
TERM 30 RELAY
TERM 87
THERMAL MANAGEMENT CONTROL UNIT
UBATT
VIO/WHT WIRE
YEL/VIO WIRE
Go to component -> 4.0l turbo hybrid, hybrid cooling fan circuit -> RED/WHT WIRE
red/wht wiring diagram (108 of 108)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CRUISE CONT MAIN SW
CRUISE CONTROL SYSTEM
ENGINE RELAY
ENGINE/MOTOR CONTROL UNIT
EXHAUST TEMPERATURE 1 +
FUEL PUMP 1
FUSE BOXES
GEAR OIL COOLING PUMP
GEARBOX OIL COOLING PUMP
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
LEFT EXHAUST-GAS FLAP
PARTICULATE FILTER 1
POWER UNIT MOUNTING SENDER 1
POWER UNIT MOUNTING SENDER 2
PRESSURE DIFFERENTIAL SENDER PETROL PARTICULATE FILTER 1
RADIATOR FAN 1
RADIATOR FAN 2 PWM
RADIATOR OUTLET
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT EXHAUST GAS FLAP
SENS GND
SENS SIG
SIG
START RELEASE PARK/NEUTRAL
STARTER RELAY 1
STARTER RELAY 2
STARTING/ CHARGING SYSTEM
STOP LIGHT SW
TANK LEAK DIAG HEATER
TANK LEAK DIAG VLV
TANK SHUT-OFF VLV
TANK VENT PRESS SENS 1 +
TANK VENT PRESS SENS 2 +
TEMP SENS AT
TEMPERATURE DIFFERENTIAL SENDER PARTICULATE FILTER
TERMINAL 50 FEEDBACK
TRANSMISSIONS SYSTEM
VALVE 1
VIO/BLU WIRE
WATER PUMP HEATING BACKUP
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 4.0l turbo hybrid, engine controls circuit (9 of 11) -> RED/WHT WIRE
