Porsche Cayenne S III (2017-2023) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car Porsche Cayenne S III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (21 of 23)

Wiring diagram nca for Porsche Cayenne S III (2017-2023)

Get access

BLU WIRE BRN WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DAZZLE + DRIVER DOOR CONTROL UNIT (IN LEFT FRONT DOOR) DRIVER SIDE EXTERIOR MIRROR FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT (IN RIGHT FRONT DOOR) FUSE 1 FUSE 14 FUSE 2 FUSE HOLDER C FUSE HOLDER D FUSE HOLDER E HOT AT ALL TIMES HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED INTERIOR MIRROR LIN MIRROR, ANTI-DAZZLE + N/A NCA WIRE PASSENGER SIDE EXTERIOR MIRROR RED WIRE RED/BLU WIRE RED/WHT WIRE TERM 15 VIO WIRE WHT WIRE

Go to component: -> Auto anti-dazzling mirror circuit -> NCA WIRE

Wiring diagram nca (22 of 23)

Wiring diagram nca for Porsche Cayenne S III (2017-2023)

Get access

BRN WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DOOR MIRROR HEATING DOOR MIRROR HEATING GND FOR ACTUATORS/SENS DRIVER DOOR CONTROL UNIT DRIVER SIDE EXTERIOR MIRROR FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT FUSE 14 FUSE 2 FUSE HOLDER C FUSE HOLDER E GND FOR ACTUATORS/SENS GND, BODY HOT AT ALL TIMES N/A NCA WIRE PASSENGER SIDE EXTERIOR MIRROR RED/WHT WIRE TERM 31 WHT WIRE

Go to component: -> Heated mirrors circuit -> NCA WIRE

Wiring diagram nca (23 of 23)

Wiring diagram nca for Porsche Cayenne S III (2017-2023)

Get access

ADJUST MIRROR, LEFT ADJUST MIRROR, RIGHT ADJUSTING MOTOR 1 ADJUSTING MOTOR 1+2 ADJUSTING MOTOR 2 BLK WIRE BRN WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM COURTESY LIGHT DOOR MIRROR HEATING DOOR MIRROR HEATING MIRROR STATUS POS Y DRIVER ASSIST SYSTEMS CONTROL UNIT DRIVER DOOR CONTROL UNIT (IN LEFT FRONT DOOR) DRIVER DOOR WINDOW REGULATOR OPERATING UNIT DRIVER SIDE EXTERIOR MIRROR FOLD MIRROR POS 1 FOLD MIRROR POS 2 FOLDING MIRROR POS 1 FOLDING MIRROR POS 2 FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT FUSE 14 FUSE 2 FUSE HOLDER C FUSE HOLDER E GND FOR ACTUATORS/SENS GND, BODY GRN/VIO WIRE HOT AT ALL TIMES LANE CHANGE ASSIST DISPLAY LH EXTR MIRR LED ON/OFF LIGHT EXTERIOR MIRROR MIRROR ADJUSTMENT SWITCH MIRROR STATUS POS Y MIRROR, ANTI-DAZZLE + MTR ADJUSTING 1 MTR ADJUSTING 1/2 MTR ADJUSTING 2 MTR ADJUSTING AXLE 1 MTR ADJUSTING AXLE 2 N/A NCA WIRE PASSENGER SIDE EXTERIOR MIRROR POTENTIOMETER REAR OVERHEAD VIEW CAMERA RED/WHT WIRE RH EXTR MIRR LED ON/OFF RIGHT OVERHEAD VIEW CAMERA RTV SCREEN D RTV SIGNAL SHIELD STATUS POS X TURN SIGNAL WARNING LIGHT EXTERIOR MIRROR WHT WIRE WHT/YEL WIRE YEL/WHT WIRE

Go to component: -> Power mirrors circuit -> NCA WIRE

Page 3 of 3
