Porsche Cayenne S III (2017-2023) masseko seat pan Wiring diagram

BAG HV- BATTERY ISOLATION UNIT BELT FORCE LIMITER + BELT TENSIONER + BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM CRASH GND CRASH SIGNAL DRIVER SIDE FRONT AIR BAG CRASH SENSOR FRONT PASSENGER SEAT PAN FRONT PASSENGER SIDE C-PILLAR REAR AIR BAG CRASH SENSOR FRONT PASSENGER SIDE CURTAIN AIR BAG IGNITER FRONT PASSENGER SIDE PEDESTRIAN PROTECTION CRASH SENSOR FRONT PASSENGER SIDE SEAT POSITION SENSOR GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE HIGH VOLTAGE BATTERY 1 LIN MASSEKO SEAT PAN NEGATIVE ORG/BRN WIRE PLUS POSITIVE POSITIVE CONNECTION DASH PANEL WIRING HARNESS (LEFT TURN SIGNAL) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BELT SWITCH RIGHT FRONT SEAT BELT SEAT HEATING IN - SEAT HEATING OUT + SEAT OCCUPIED RECOGNITION CONTROL UNIT SEATS SYSTEM SHIELDING SIGNAL SIGNAL GND TERM 15 TERM 30 TERM 31 VIO WIRE VIO/RED WIRE W/ TENSIONER HEIGHT ADJUSTMENT W/O TENSIONER HEIGHT ADJUSTMENT WHT WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/GRY WIRE
