Porsche Cayenne S III (2017-2023) lr cen vent blow out temp Wiring diagram

ACT/SENS GROUND AIR CONDITIONING SYSTEM CONTROL UNIT BLK/BRN WIRE BLK/YEL WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE CAN COMFORT 2 HIGH CAN COMFORT 2 LOW COMPUTER DATA LINES SYSTEM FRONT FUSE BOX FUSE 11 FUSE 4 FUSE HOLDER C FUSE HOLDER H GRN/YEL WIRE GROUND HOT AT ALL TIMES LEFT "B" PILLAR, FOOTWELL SHUT-OFF FLAP CONTROL MOTOR LEFT FRONT CHEST VENT TEMPERATURE SENSOR LEFT INDIRECT VENTILATION FLAP CONTROL MOTOR LEFT POTENTIOMETER SIG LEFT REAR CHEST VENT CONTROL MOTOR LH EMITTER + LH SIDE VENT TEMP SENS LIN 3 LIN 4 LIN 5 LIN INPUT LIN OUTPUT LR CEN VENT BLOW OUT TEMP LR FOOTWELL BLOW OUT TEMP N/A ORG/BRN WIRE REAR FUSE BOX RED WIRE RED/GRN WIRE RED/YEL WIRE RH SIDE VENT TEMP SENS RIGHT "B" PILLAR, FOOTWELL SHUT-OFF FLAP CONTROL MOTOR RIGHT INDIRECT VENTILATION FLAP CONTROL MOTOR RIGHT POTENTIOMETER SIG RIGHT REAR CHEST VENT CONTROL MOTOR RR CEN VENT BLOW OUT TEMP RR FOOTWELL BLOW OUT TEMP SEATS SYSTEM SUPPLY TERM 30 TERM 31 VIO/RED WIRE VIO/WHT WIRE W/ REAR A/C (HIGH) W/ REAR A/C (LOW) WHT WIRE WHT/GRN WIRE
