Porsche Cayenne S III (2017-2023) gps ant Wiring diagram
This page shows the only wiring diagram for the component.gps ant, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gps ant (1 of 1)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE HOLDER J
GPS ANT
GROUND
HOT AT ALL TIMES
LTE ANT DIVERSITY
LTE ANT PRIMARY
N/A
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
REAR FUSE BOX
RED/WHT WIRE
SHIELD
T CAN HIGH
T CAN LOW
TERM 30
VEHICLE LOCATION SYSTEM AERIAL 1
VEHICLE LOCATION SYSTEM CONTROL UNIT
Go to component: -> Vehicle positioning system circuit -> GPS ANT
