Porsche Cayenne S III (2017-2023) gps aerial 2 Wiring diagram
This page shows the only wiring diagram for the component.gps aerial 2, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gps aerial 2 (1 of 1)
BLK WIRE
BRN WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
CAN HIGH
CAN LOW
DATA BUS DIAGNOSTIC INTERFACE
DRIVER DOOR CONTROL UNIT
FRONT PASSENGER DOOR CONTROL UNIT
GPS
GPS AERIAL 2
GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GSM 1
GSM 2
GSM AERIAL
GSM AERIAL 2
GSM SIG
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
NCA WIRE
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
PNK WIRE
REAR LID POWER OPENING CONTROL UNIT
REAR SPOILER ADJUSTABLE CONTROL UNIT
RED WIRE
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
SHIELD
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
STEERING COLUMN LOCK CONTROL ELEMENT
SUNROOF ROLLER BLIND CONTROL UNIT
TAN WIRE
TRAILER DETECTOR CONTROL UNIT
WHT WIRE
Go to component: -> Computer data lines circuit (5 of 6) -> GPS AERIAL 2
