Porsche Cayenne S III (2017-2023) fuse holder s Wiring diagrams
This page contains all the electrical diagrams for the component. fuse holder s, in which he is found in the car Porsche Cayenne S III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fuse holder s wiring diagram (1 of 3)
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
FRONT FUSE BOX
FUSE HOLDER S
GRN/RED WIRE
GRY/BRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT BACKREST ADJUSTMENT MOTOR
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
LEFT FRONT SEAT LONGITUDINAL ADJUSTMENT MOTOR
LEFT FRONT SEAT RAKE ADJUSTMENT MOTOR
LEFT SEAT ADJUSTMENT CIRCUIT BREAKER
N/A
RED/BLK WIRE
WHT WIRE
WHT/RED WIRE
Go to component -> Driver power seat circuit -> FUSE HOLDER S
fuse holder s wiring diagram (2 of 3)
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CAN HIGH
CAN LOW
CODING PIN (DS-PS)
COMPUTER DATA LINES SYSTEM
DRIVER MULTI-CONTOUR SEAT CONTROL UNIT
DRIVER SEAT MULTI-CONTOUR COMPRESSOR
FRONT FUSE BOX
FUSE HOLDER S
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT MASSAGE SEAT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT SEAT ADJUSTMENT CIRCUIT BREAKER
LIN
LIN 2
LNV TASTER
LUMBAR FORWARD/BACK
LUMBAR HIGH LOW
MASSAGE
ORG/BRN WIRE
PUMP
RED/BLK WIRE
RED/BLU WIRE
SEAT BACKREST BOLSTER ADJ
SEAT CUSHION BOLSTER ADJ
SEAT CUSHION DEPTH ADJ
SHV TASTER
SLV TASTER
SNV TASTER
STV TASTER
SUPPLY
TERM 30
TERM 30 S
TERM 30 SWITCHED
TERM 31
VIO/BLU WIRE
WHT WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> FUSE HOLDER S
fuse holder s wiring diagram (3 of 3)
AIR BAG CONTROL UNIT
AIR HUMIDITY RAIN, LIGHT SENSOR
BLK WIRE
BLK/GRN WIRE
DATA BUS DIAGNOSTIC INTERFACE
DIAGNOSTIC CONNECTION
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE/ MOTOR CONTROL UNIT
FROM BATTERY ISOLATION UNIT (DIAGRAM 1 OF 9)
FRONT FUSE BOX
FRONT PASSENGER DOOR CONTROL UNIT
FRONT ROOF MODULE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE CARRIER 6
FUSE CARRIER 7
FUSE HOLDER E
FUSE HOLDER S
GEARBOX HYDRAULIC PUMP
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT SEAT ADJUSTMENT CIRCUIT BREAKER
MAIN RELAY
N/A
ONBOARD SUPPLY CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
SELECTOR LEVER SENSORS CONTROL UNIT
SIREN
TELEPHONE, TELEMATICS CONTROL UNIT
TO FUSE HOLDER B (DIAGRAM 5 OF 9)
TO FUSE HOLDER C (DIAGRAM 2 OF 9)
TO TERMINAL 15 VOLTAGE SUPPLY RELAY (DIAGRAM 2 OF 9)
WHT WIRE
WHT/BRN WIRE
Go to component -> Power distribution circuit (4 of 9) -> FUSE HOLDER S
