Porsche Cayenne S III (2017-2023) front passenger side sun visor Wiring diagram
This page shows the only wiring diagram for the component.front passenger side sun visor, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger side sun visor (1 of 1)
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/VIO WIRE
CENTER VENT
DRIVER SIDE SUN VISOR
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
FRONT PASSENGER SIDE SUN VISOR
FRONT ROOF MODULE
GROUND
GRY/BLU WIRE
LED
LEFT DASH PANEL VENT ILLUMINATION BULB
LEFT REAR BUTTON
LEFT REAR INTERIOR LIGHT
LIN 6
NEGATIVE
POSITIVE
READING LIGHT
REAR CENTER VENT
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT DASH PANEL VENT ILLUMINATION BULB
RIGHT REAR BUTTON
RIGHT REAR INTERIOR LIGHT
SWITCH
SYMBOL
TERM 30
TERM 31
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
WHT/RED WIRE
Go to component: -> Interior lights circuit (4 of 8) -> FRONT PASSENGER SIDE SUN VISOR
