Porsche Cayenne S III (2017-2023) front passenger seat memory operating unit Wiring diagrams

BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DOOR GUARD LIGHT EXIT WARN LAMP FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER DOOR STORAGE COMPARTMENT ILLUMINATION BULB FRONT PASSENGER DOOR WINDOW REGULATOR SWITCH FRONT PASSENGER SEAT MEMORY OPERATING UNIT FRONT PASSENGER SIDE CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON FRONT PASSENGER SIDE LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING FUSE 14 FUSE HOLDER E GROUND HOT AT ALL TIMES INNER DOOR HANDLE LIGHTING LIN LIN INPUT LIN OUTPUT N/A PASSENGER DOOR BACKGROUND LIGHTING PASSENGER DOOR BACKGROUND LIGHTING 2 PASSENGER SIDE ENTRY LIGHT PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LIGHT POWER RED/GRN WIRE RED/WHT WIRE TERM 30 TERM 31 VIO/BLK WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/VIO WIRE

1 2 MEMORY BUTTON BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE BUTTON MODULE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER SEAT DEPTH ADJUSTMENT MOTOR FRONT PASSENGER SEAT MEMORY OPERATING UNIT FRONT PASSENGER SIDE LUMBAR SUPPORT ADJUSTMENT MOTOR FUNCTION LED FUSE 14 FUSE HOLDER E GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HALL HALL LNV HALL SENSOR HALL SHV HALL SLV HALL SNV HALL STV HORIZONTAL LUMBAR HOT AT ALL TIMES LUMBAR ROTARY SWITCH MASSAGE BUTTON MASSE POTI MEMORY BUTTON LED MEMORY MODULE MEMORY BUTTON MOTOR + SHV MOTOR + SLV MOTOR - SNV MOTOR-LNV N/A RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BACKREST ADJUSTMENT MOTOR RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT RIGHT FRONT SEAT HEIGHT ADJUSTMENT MOTOR RIGHT FRONT SEAT LONGITUDINAL ADJUSTMENT MOTOR RIGHT FRONT SEAT RAKE ADJUSTMENT MOTOR STV 1 STV 2 TERM 31 VE+ MOTOR VERTICAL LUMBAR VIO/GRN WIRE VIO/YEL WIRE WHT WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE
