Porsche Cayenne S III (2017-2023) folding mirror pos 2 Wiring diagrams

This page contains all the electrical diagrams for the component. folding mirror pos 2, in which he is found in the car Porsche Cayenne S III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram folding mirror pos 2 (1 of 2)

Wiring diagram folding mirror pos 2 for Porsche Cayenne S III (2017-2023)

Get access

1 2 MEMORY BUTTON ADJUST MIRROR, LEFT ADJUST MIRROR, RIGHT ADJUSTING MOTOR 1 ADJUSTING MOTOR 1+2 ADJUSTING MOTOR 2 ADJUSTING MTR 1/2 BLK WIRE BRN WIRE BUTTON MODULE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM COURTESY LIGHT DOOR MIRROR HEATING DOOR MIRROR HEATING MIRROR STATUS POS Y DRIVER ASSIST SYSTEMS CONTROL UNIT DRIVER DOOR CONTROL UNIT (IN DRIVER FRONT DOOR) DRIVER DOOR WINDOW REGULATOR OPERATING UNIT DRIVER SEAT MEMORY OPERATING UNIT DRIVER SIDE EXTERIOR MIRROR FOLD MIRROR POS 1 FOLD MIRROR POS 2 FOLDING MIRROR POS 1 FOLDING MIRROR POS 2 FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT FUNCTION LED FUSE 14 FUSE 2 FUSE HOLDER C FUSE HOLDER E GND FOR ACTUATORS/SENS GND, BODY GRN/VIO WIRE GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES LANE CHANGE ASSIST DISPLAY LH EXTR MIRR LED ON/OFF LIGHT EXTERIOR MIRROR LVDS TV LEFT MEMORY BUTTON MEMORY BUTTON LED MEMORY MODULE METER ADJUSTING 1/2 MIRROR ADJUSTMENT SWITCH MIRROR POS 1 MIRROR POS 2 MIRROR STATUS POS Y MIRROR, ANTI-DAZZLE + MTR ADJUSTING 1 MTR ADJUSTING 1/2 MTR ADJUSTING 2 MTR ADJUSTING AXLE X MTR ADJUSTING AXLE Y N/A NCA WIRE PASSENGER SIDE EXTERIOR MIRROR POTENTIOMETER REAR OVERHEAD VIEW CAMERA RED/WHT WIRE RH EXTR MIRR LED ON/OFF RIGHT OVERHEAD VIEW CAMERA RTV SCREEN RTV SIGNAL SHIELD STATUS POS X TERM 31 TURN SIGNAL VIO/GRN WIRE VIO/YEL WIRE WARNING LIGHT EXTERIOR MIRROR WHT WIRE WHT/YEL WIRE YEL/WHT WIRE

Go to component: -> Memory mirrors circuit -> FOLDING MIRROR POS 2

Wiring diagram folding mirror pos 2 (2 of 2)

Wiring diagram folding mirror pos 2 for Porsche Cayenne S III (2017-2023)

Get access

ADJUST MIRROR, LEFT ADJUST MIRROR, RIGHT ADJUSTING MOTOR 1 ADJUSTING MOTOR 1+2 ADJUSTING MOTOR 2 BLK WIRE BRN WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM COURTESY LIGHT DOOR MIRROR HEATING DOOR MIRROR HEATING MIRROR STATUS POS Y DRIVER ASSIST SYSTEMS CONTROL UNIT DRIVER DOOR CONTROL UNIT (IN LEFT FRONT DOOR) DRIVER DOOR WINDOW REGULATOR OPERATING UNIT DRIVER SIDE EXTERIOR MIRROR FOLD MIRROR POS 1 FOLD MIRROR POS 2 FOLDING MIRROR POS 1 FOLDING MIRROR POS 2 FRONT FUSE BOX FRONT PASSENGER DOOR CONTROL UNIT FUSE 14 FUSE 2 FUSE HOLDER C FUSE HOLDER E GND FOR ACTUATORS/SENS GND, BODY GRN/VIO WIRE HOT AT ALL TIMES LANE CHANGE ASSIST DISPLAY LH EXTR MIRR LED ON/OFF LIGHT EXTERIOR MIRROR MIRROR ADJUSTMENT SWITCH MIRROR STATUS POS Y MIRROR, ANTI-DAZZLE + MTR ADJUSTING 1 MTR ADJUSTING 1/2 MTR ADJUSTING 2 MTR ADJUSTING AXLE 1 MTR ADJUSTING AXLE 2 N/A NCA WIRE PASSENGER SIDE EXTERIOR MIRROR POTENTIOMETER REAR OVERHEAD VIEW CAMERA RED/WHT WIRE RH EXTR MIRR LED ON/OFF RIGHT OVERHEAD VIEW CAMERA RTV SCREEN D RTV SIGNAL SHIELD STATUS POS X TURN SIGNAL WARNING LIGHT EXTERIOR MIRROR WHT WIRE WHT/YEL WIRE YEL/WHT WIRE

Go to component: -> Power mirrors circuit -> FOLDING MIRROR POS 2
