Porsche Cayenne S III (2017-2023) climatronic operating unit wiring harness Wiring diagram
This page shows the only wiring diagram for the component.climatronic operating unit wiring harness, which is found in the car Porsche Cayenne S III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram climatronic operating unit wiring harness (1 of 1)
AIR HUMIDITY RAIN, LIGHT SENSOR
ANTI-ROLL BAR CONTROL UNIT 2
AXLE DIFFERENTIAL LOCK CONTROL UNIT
BRN WIRE
BRN/VIO WIRE
CLIMATRONIC OPERATING UNIT WIRING HARNESS
CLIMATRONIC WIRING HARNESS, RADIATOR FAN
ENGINE SOUND GENERATOR CONTROL UNIT
EXHAUST FLAP CONTROL UNIT
EXHAUST FLAP CONTROL UNIT 2
FRONT ANTI-ROLL BAR CONTROL UNIT
FRONT ROOF MODULE
FUSE CARRIER 5
GARAGE DOOR OPERATION CONTROL UNIT
HEATED REAR WINDOW RELAY
HIGH VOLTAGE BATTERY CHARGING UNIT 1
INTERIOR MIRROR
LANE CHANGE ASSIST CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT 2
LEFT "C" PILLAR)
LEFT EXHAUST FLAP CONTROL UNIT 2
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT REAR BRAKE PAD WEAR SENDER
LEFT REAR SEAT HEATING CONTROL
LEFT TAIL LIGHT CLUSTER
ONBOARD SUPPLY CONTROL UNIT 2
OPENING EXHAUST FLAP 2 CONTROL UNIT 2
PTC HEATER ELEMENT 1
REAR ANTI-ROLL BAR CONTROL UNIT 2
REAR LID POWER OPENING SENDER
RELAY CARRIER 6
RIGHT EXHAUST FLAP CONTROL UNIT 2
SEAT VENTILATION RELAY
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
SUBWOOFER
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
TRAILER DETECTOR CONTROL UNIT
VIO/BRN WIRE
YEL WIRE
Go to component: -> Ground distribution circuit (6 of 8) -> CLIMATRONIC OPERATING UNIT WIRING HARNESS
