Porsche Cayenne GTS III (2017-2023) air bag pulse width modulation Wiring diagram
This page shows the only wiring diagram for the component.air bag pulse width modulation, which is found in the car Porsche Cayenne GTS III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag pulse width modulation (1 of 1)
AIR BAG PULSE WIDTH MODULATION
BLK WIRE
BRN WIRE
BRN/BLU WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT
ETHERNET
FRONT FUSE BOX
FRONT ROOF MODULE
FUSE 2
FUSE 9
FUSE HOLDER D
FUSE HOLDER E
GPS AERIAL 2
GRN WIRE
GROUND
GRY/YEL WIRE
GSM AERIAL
GSM AERIAL 2
GSM ANTENNA
GSM ANTENNA 3
HANDS FREE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
IGNITION ON (TERMINAL 15)
MICROPHONE
MICROPHONE 1 -
MICROPHONE 1 - (ROOF CONSOLE)
MULTIMEDIA SYSTEM
N/A
NCA WIRE
ORG/BRN WIRE
PNK WIRE
POS CONNECTION 2
REAR RIGHT DOOR WIRING HARNESS CONNECTION 3
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
SHIELD
SPEAKER
TERM 30
VDA LF+
VDA LFNC
VDA MUTE
VDA OUT +
WHT WIRE
YEL/BLK WIRE
Go to component -> Emergency call circuit -> AIR BAG PULSE WIDTH MODULATION
