Porsche Cayenne GTS II (2010-2014) trim 31 Wiring diagram
This page shows the only wiring diagram for the component.trim 31, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trim 31 (1 of 1)
BLU WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FL SUPPLY
FR SUPPLY
FUSE 8
GP-31
GROUND
HOT W/ TERMINAL
LEFT FRONT TPM TRIGGER MODULE
LEFT FUSE BOX
LEFT REAR TPM TRIGGER MODULE
ORG/BRN WIRE
ORG/VIO WIRE
PWM DATA
PWM GROUND
RDK CONTROL UNIT
RED/BRN WIRE
RIGHT FRONT TPM TRIGGER MODULE
RIGHT REAR TRIGGER MODULE
RL SUPPLY
RR SUPPLY
SIGNAL
SUPPLAY
SUPPLY
TRIM 31
YEL WIRE
Go to component: -> Warning systems circuit -> TRIM 31
