Porsche Cayenne GTS II (2010-2014) term 31 gnd Wiring diagram
This page shows the only wiring diagram for the component.term 31 gnd, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram term 31 gnd (1 of 1)
ALL-WHEEL DRIVE CONTROL UNIT
BLK WIRE
BLK/RED WIRE
BRN WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE 30
FUSE 43
GP-26
HOT AT ALL TIMES
HOT W/ TERM 15 RELAY ENERGIZED
ORG/BRN WIRE
ORG/RED WIRE
RED WIRE
RED/WHT WIRE
RIGHT FUSE BOX
TERM 15
TERM 30
TERM 31 GND
TERMINAL 30
WHT WIRE
Go to component: -> Awd circuit -> TERM 31 GND
