Porsche Cayenne GTS II (2010-2014) temp rad line Wiring diagrams

This page contains all the electrical diagrams for the component. temp rad line, in which he is found in the car Porsche Cayenne GTS II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram temp rad line (1 of 2)

Wiring diagram temp rad line for Porsche Cayenne GTS II (2010-2014)

Get access

BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE PEDAL SWITCH BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT SENS CAMSHAFT SENS 2 CHARGE AIR TEMPERATURE SENSOR CRANKSHAFT SPEED SENSOR DIVERTER VLV DME CONTROL UNIT (RIGHT REAR ENGINE COMPT) ENG SENS 2 GND ENG SENS 3 GND ENGINE COMPARTMENT TEMPERATURE SENSOR FUEL INJ 2 FUEL INJ 4 FUEL INJ 7 FUEL INJ 8 GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE IGNITION CYL 2 IGNITION CYL 5 IGNITION CYL 6 IGNITION CYL 8 INTAKE MAN PRESSURE SENSOR KNOCK 1 GND KNOCK 2 GND KNOCK 3 GND KNOCK 4 GND NTC- O/P OIL PRESSURE/ TEMPERATURE SENSOR PR SIG RAIL PRESSURE SENSOR REAR BCM RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RLY TERM 50 SIG SPD SEN SIG STOP LT SW TEMP OIL LEVEL TEMP RAD LINE TERM 15 TERM 15 SV TERM 31 TERM 87 THRO VLV GND THRO VLV SPLY TRAILER HITCH CONTROL UNIT TURBO VALVE WHT WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLU WIRE

Go to component: -> Wiring diagram engine performance 4.8l (3 of 5) -> TEMP RAD LINE

Wiring diagram temp rad line (2 of 2)

Wiring diagram temp rad line for Porsche Cayenne GTS II (2010-2014)

Get access

BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE PEDAL SWITCH BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT SENS CAMSHAFT SENS 2 CHARGE AIR TEMPERATURE SENSOR CRANKSHAFT SPEED SENSOR DIVERTER VLV DME CONTROL UNIT (RIGHT REAR ENGINE COMPT) ENG SENS 2 GND ENG SENS 3 GND ENGINE COMPARTMENT TEMPERATURE SENSOR FUEL INJ 2 FUEL INJ 4 FUEL INJ 7 FUEL INJ 8 GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE IGNITION CYL 2 IGNITION CYL 5 IGNITION CYL 6 IGNITION CYL 8 INTAKE MAN PRESSURE SENSOR KNOCK 1 GND KNOCK 2 GND KNOCK 3 GND KNOCK 4 GND NTC- O/P OIL PRESSURE/ TEMPERATURE SENSOR PR SIG RAIL PRESSURE SENSOR REAR BCM RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RLY TERM 50 SIG SPD SEN SIG STOP LT SW TEMP OIL LEVEL TEMP RAD LINE TERM 15 TERM 15 SV TERM 31 TERM 87 THRO VLV GND THRO VLV SPLY TRAILER HITCH CONTROL UNIT TURBO VALVE WHT WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLU WIRE

Go to component: -> Wiring diagram engine performance 4.8l twin turbo (3 of 5) -> TEMP RAD LINE
