Porsche Cayenne GTS II (2010-2014) telephone hf in Wiring diagrams

This page contains all the electrical diagrams for the component. telephone hf in, in which he is found in the car Porsche Cayenne GTS II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram telephone hf in (1 of 6)

Wiring diagram telephone hf in for Porsche Cayenne GTS II (2010-2014)

Get access

AMPLIFIER SW OUT ANTENNA AUX 1 IN L + AUX 1 RTN AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLK/RED WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CHARGER POWER DATA DATA (+) VCC DATA (-) GND GPS ANTENNA GPS HF IN GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE PWR LVDS LVDS IN + MICROPHONE MICROPHONE SHLD ORG/ WIRE OUT PORSCHE COMMUNICATION MANAGEMENT (PCM) REAR PDC SOUND EMITTER RED WIRE RR LOUD + SDARS ANT SDARS ANTENNA SHIELD SHLD TELEPHONE HF IN TV TUNER CIRCUIT UNIVERSAL MULTIMEDIA INTERFACE (UMS) VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

Go to component: -> Navigation circuit, w/ ask (1 of 3) -> TELEPHONE HF IN

Wiring diagram telephone hf in (2 of 6)

Wiring diagram telephone hf in for Porsche Cayenne GTS II (2010-2014)

Get access

ANTENNA AUX 1 IN L + AUX 1 RTN AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CHARGER POWER DATA DATA (+) VCC DATA (-) GND GPS ANTENNA GPS HF IN GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE PWR LVDS LVDS IN + MICROPHONE MICROPHONE SHLD ORG/ WIRE OUT PORSCHE COMMUNICATION MANAGEMENT (PCM) REAR PDC SOUND EMITTER RED WIRE RR LOUD + SDARS ANT SDARS ANTENNA SHIELD SHLD TELEPHONE HF IN TV TUNER CIRCUIT UNIVERSAL MULTIMEDIA INTERFACE (UMS) VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

Go to component: -> Navigation circuit, w/ bose (1 of 3) -> TELEPHONE HF IN

Wiring diagram telephone hf in (3 of 6)

Wiring diagram telephone hf in for Porsche Cayenne GTS II (2010-2014)

Get access

ANTENNA AUX 1 IN L + AUX 1 RTN AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CHARGER POWER DATA DATA (+) VCC DATA (-) GND GPS ANTENNA GPS HF IN GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE PWR LVDS LVDS IN + MICROPHONE MICROPHONE SHLD ORG/ WIRE OUT PORSCHE COMMUNICATION MANAGEMENT (PCM) REAR PDC SOUND EMITTER RED WIRE RR LOUD + SDARS ANT SDARS ANTENNA SHIELD SHLD TELEPHONE HF IN TV TUNER CIRCUIT UNIVERSAL MULTIMEDIA INTERFACE (UMS) VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

Go to component: -> Navigation circuit, w/ burmester (1 of 4) -> TELEPHONE HF IN

Wiring diagram telephone hf in (4 of 6)

Wiring diagram telephone hf in for Porsche Cayenne GTS II (2010-2014)

Get access

AMPLIFIER SW OUT ANTENNA AUX 1 IN L + AUX 1 RTN AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLK/RED WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CHARGER POWER DATA DATA (+) VCC DATA (-) GND GPS ANTENNA GPS HF IN GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE PWR LVDS LVDS IN + MICROPHONE MICROPHONE SHLD ORG/ WIRE OUT PORSCHE COMMUNICATION MANAGEMENT (PCM) REAR PDC SOUND EMITTER RED WIRE RR LOUD + SDARS ANT SDARS ANTENNA SHIELD SHLD TELEPHONE HF IN TV TUNER CIRCUIT UNIVERSAL MULTIMEDIA INTERFACE (UMS) VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

Go to component: -> Premium radio circuit, w/ ask (1 of 3) -> TELEPHONE HF IN

Wiring diagram telephone hf in (5 of 6)

Wiring diagram telephone hf in for Porsche Cayenne GTS II (2010-2014)

Get access

ANTENNA AUX 1 IN L + AUX 1 RTN AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CHARGER POWER DATA DATA (+) VCC DATA (-) GND GPS ANTENNA GPS HF IN GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE PWR LVDS LVDS IN + MICROPHONE MICROPHONE SHLD ORG/ WIRE OUT PORSCHE COMMUNICATION MANAGEMENT (PCM) REAR PDC SOUND EMITTER RED WIRE RR LOUD + SDARS ANT SDARS ANTENNA SHIELD SHLD TELEPHONE HF IN TV TUNER CIRCUIT UNIVERSAL MULTIMEDIA INTERFACE (UMS) VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

Go to component: -> Premium radio circuit, w/ bose (1 of 3) -> TELEPHONE HF IN

Wiring diagram telephone hf in (6 of 6)

Wiring diagram telephone hf in for Porsche Cayenne GTS II (2010-2014)

Get access

ANTENNA AUX 1 IN L + AUX 1 RTN AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CHARGER POWER DATA DATA (+) VCC DATA (-) GND GPS ANTENNA GPS HF IN GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE PWR LVDS LVDS IN + MICROPHONE MICROPHONE SHLD ORG/ WIRE OUT PORSCHE COMMUNICATION MANAGEMENT (PCM) REAR PDC SOUND EMITTER RED WIRE RR LOUD + SDARS ANT SDARS ANTENNA SHIELD SHLD TELEPHONE HF IN TV TUNER CIRCUIT UNIVERSAL MULTIMEDIA INTERFACE (UMS) VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

Go to component: -> Premium radio circuit, w/ burmester (1 of 4) -> TELEPHONE HF IN
