Porsche Cayenne GTS II (2010-2014) selector lever sply Wiring diagram
This page shows the only wiring diagram for the component.selector lever sply, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever sply (1 of 1)
BCM (LEFT SIDE OF DASH)
BLK/BLU WIRE
BLK/RED WIRE
BLU/BRN WIRE
BRN WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FUSE 10
GP-21
GP-22
GP-22 (RIGHT SIDE OF DASH)
GRY/WHT WIRE
HOT W/ MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PARK
PLENUM PANEL FUSE BOX
POSITION
RED/GRN WIRE
SELECTOR LEVER
SELECTOR LEVER CONTROL UNIT
SELECTOR LEVER POS
SELECTOR LEVER SPLY
SHIFTLOCK -
SIGNAL
STOP LAMP SW
STOPLIGHT SWITCH
TERMINAL 30
TERMINAL 31
TERMINAL 87
TRANSMISSION CONTROL UNIT
WHT/BLU WIRE
YEL/BRN WIRE
Go to component: -> Shift interlock circuit -> SELECTOR LEVER SPLY
