Porsche Cayenne GTS II (2010-2014) seat frt low Wiring diagrams

This page contains all the electrical diagrams for the component. seat frt low, in which he is found in the car Porsche Cayenne GTS II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram seat frt low (1 of 2)

Wiring diagram seat frt low for Porsche Cayenne GTS II (2010-2014)

Get access

ADJUST BACK ADJUST FWD ADJUSTMENT BACK ADJUSTMENT FWD AFT ADJ 1 AFT ADJ 2 ANGLE ADJ 1 ANGLE ADJ 2 BACKREST ADJ 1 BACKREST ADJ 2 BLU WIRE BRN WIRE DRIVER SEAT ADJUSTMENT OPTICAL CONTROL UNIT DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR FUSE 1 GRN WIRE GRY WIRE HEIGHT ADJ 1 HEIGHT ADJ 2 HOT W/ LEFT FUSE BOX PIPE FRAME SERVO MOTOR RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED SEAT FRT HIGH SEAT FRT LOW SEAT REAR HIGH SEAT REAR LOW TERMINAL 30 TERMINAL 31 VIO WIRE

Go to component: -> Driver power seat circuit -> SEAT FRT LOW

Wiring diagram seat frt low (2 of 2)

Wiring diagram seat frt low for Porsche Cayenne GTS II (2010-2014)

Get access

ADJUST BACK ADJUST FWD ADJUSTMENT BACK ADJUSTMENT FWD AFT ADJ 1 AFT ADJ 2 ANGLE ADJ 1 ANGLE ADJ 2 BACKREST ADJ 1 BACKREST ADJ 2 BLU WIRE BRN WIRE FRONT PASSENGER SEAT ADJUSTMENT OPTICAL CONTROL UNIT FRONT PASSENGER SEAT BACKREST ADJUSTMENT MOTOR FUSE 20 GP-26 GRN WIRE GRY WIRE HEIGHT ADJ 1 HEIGHT ADJ 2 HOT W/ PIPE FRAME SERVO MOTOR RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FUSE BOX SEAT FRT HIGH SEAT FRT LOW SEAT REAR HIGH SEAT REAR LOW TERMINAL 30 TERMINAL 31 VIO WIRE

Go to component: -> Passenger power seat circuit -> SEAT FRT LOW
