Porsche Cayenne GTS II (2010-2014) right two-tone horn Wiring diagrams
This page contains all the electrical diagrams for the component. right two-tone horn, in which he is found in the car Porsche Cayenne GTS II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right two-tone horn (1 of 2)
2/3-WAY VALVE
3.0L HYBRID
ACC CONTROL UNIT
BLK WIRE
BRN WIRE
CIRCULATING PUMP AUXILIARY HEATER
ELECTRIC A/C COMPRESSOR
ELECTRIC DRIVE
ELECTRIC DRIVE POWER ELECTRONICS
ENGINE LID SWITCH
GP-5 (BEHIND LEFT HEADLIGHT)
GP-6 (BEHIND RIGHT HEADLIGHT)
GP-MB DC
GP-MB EM
GP-MB HV
GP-MB LE
HEADLIGHT WASHER FLUID PUMP
HIGH VOLTAGE BATTERY SYSTEM
LEFT AUXILIARY HEADLIGHT
LEFT FRONT BRAKE PAD WEAR INDICATOR
LEFT FRONT FOG LIGHT
LEFT FRONT HEATED SPRAY JET
LEFT HEADLIGHT
LEFT SIDE TURN SIGNAL
LEFT TWO-TONE HORN
PARKING HEATER CONTROL UNIT
RIGHT AUXILIARY HEADLIGHT
RIGHT FRONT FOG LIGHT
RIGHT FRONT HEATED SPRAY JET
RIGHT HEADLIGHT
RIGHT SIDE TURN SIGNAL
RIGHT TWO-TONE HORN
SPINDLE ACTUATOR
TRANSMISSION OIL PUMP DRIVER
W/ DRL
W/O DRL
YEL WIRE
Go to component -> Ground distribution circuit (1 of 6) -> RIGHT TWO-TONE HORN
Wiring diagram right two-tone horn (2 of 2)
BRN WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
CAN COMFORT LOW CAN COMFORT HIGH
COMPUTER DATA LINES SYSTEM
FRONT BCM
FUSE 3
GP-23
GP-5
HOT AT ALL TIMES
LEFT FUSE BOX
LEFT TWO-TONE HORN
ORG/BRN WIRE
ORG/GRN WIRE
RIGHT TWO-TONE HORN
STEERING COLUMN SWITCHING MODULE
TWO-TONE HORNS RELAY
TWO-TONE HORNS RLY
VIO WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component -> Horn circuit -> RIGHT TWO-TONE HORN
