Porsche Cayenne GTS II (2010-2014) right rear a/c unit air flow driver link Wiring diagram

BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE CENT LOCK BUTTON COMPUTER DATA LINES SYSTEM FUSE 10 FUSE 21 FUSE 22 FUSE 25 FUSE 44 FUSE 48 FUSE 50 FUSE 57 FUSE 8 GP-22 GRN/YEL WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER LEFT FUSE BOX LEFT REAR A/C UNIT AIR FLOW DRIVER LINK LEFT REAR DRIVE LINK PASSENGER BLOWER "B" PILLAR LEFT REAR DRIVE LINK PASSENGER BLOWER TUNNEL LEFT REAR TEMPERATURE VALVE SERVO MOTOR LEFT SEAT HEATER LEFT SEAT TEMP LIN LIN INPUT LIN OUTPUT MAIN FUSE BOX ORG/BRN WIRE ORG/VIO WIRE REAR A/C OPERATING UNIT RED WIRE RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FUSE BOX RIGHT REAR A/C UNIT AIR FLOW DRIVER LINK RIGHT REAR DRIVE LINK PASSENGER BLOWER B-PILLAR RIGHT REAR DRIVE LINK PASSENGER BLOWER TUNNEL RIGHT REAR TEMPERATURE VALVE SERVO MOTOR RIGHT SEAT HEATER RIGHT SEAT TEMP SEATS SYSTEM SIGNAL GROUND TERM 30 TERM 31 TERM 58 D VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT/YEL WIRE ZV FUNCTION INDICATOR
