Porsche Cayenne GTS II (2010-2014) porsche right front seat entertainment module Wiring diagrams

This page contains all the electrical diagrams for the component. porsche right front seat entertainment module, in which he is found in the car Porsche Cayenne GTS II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram porsche right front seat entertainment module (1 of 2)

Wiring diagram porsche right front seat entertainment module for Porsche Cayenne GTS II (2010-2014)

Get access

3.0L DIESEL A/C CONTROL UNIT AIR QUALITY SENSOR ALL-WHEEL DRIVE CONTROL UNIT AUTOMATIC TRANSMISSION BATTERY SENSOR BLK WIRE BRN WIRE CENTER CONSOLE CIGAR LIGHTER CENTER CONSOLE REAR PLUG SOCKET 1 CENTER CONSOLE STORAGE BIN SOCKET CHASSIS CONTROL SWITCH COMPASS ELECTRONIC IGNITION LOCK EXHAUST FLAP VALVE FRESH AIR FAN MOTOR FROM GROUND GP-20 (DIAGRAM 3 OF 6) FROM SUPER CHARGER LEVEL CONTROL (DIAGRAM 5 OF 6) FRONT BCM FRONT LIGHT ASHTRAY GLOVE BOX SWITCH GP-22 (RIGHT SIDE OF DASH) GP-23 (LEFT SIDE OF DASH) GP-24 GP-25 GP-26 HAND BRAKE SWITCH IGNITION LOCK LIGHT INSTRUMENT CLUSTER IRU DEACTIVATION BUTTON LEFT B-PILLAR AIR VENT LIGHTING LEFT COCKPIT AIR VENT LIGHTING LEFT COCKPIT CENTER AIR VENT LIGHTING LEFT REAR CENTER AIR VENT LIGHTING LEFT TOP LOADER MOBILE PHONE CHARGING TRAY NOX SENSOR 1 NOX SENSOR 2 ODDMENTS TRAY LIGHTING PARTICLE SENSOR PDCC CONTROL UNIT PORSCHE RIGHT FRONT SEAT ENTERTAINMENT MODULE PTC HEATER REAR A/C OPERATING UNIT REAR DIFFERENTIAL LOCK CONTROL UNIT REAR REVERSING LIGHT/ FOG LIGHT REAR WINDOW HEATER RELAY RESIDUAL HEAT RELAY RIGHT B-PILLAR AIR VENT LIGHTING RIGHT COCKPIT AIR VENT LIGHTING RIGHT COCKPIT CENTER AIR VENT LIGHTING RIGHT FRONT BLUETOOTH CHARGING TRAY RIGHT REAR CENTER AIR VENT LIGHTING SELECTOR LEVER CONTROL UNIT STEERING COLUMN LOCK SUN SENSOR TRANSMISSION CONTROL UNIT TRANSMISSION OIL SHUTOFF VALVE TWO-TONE HORNS RELAY W/ BLUETOOTH W/O BLUETOOTH

Go to component: -> Ground distribution circuit (4 of 6) -> PORSCHE RIGHT FRONT SEAT ENTERTAINMENT MODULE

Wiring diagram porsche right front seat entertainment module (2 of 2)

Wiring diagram porsche right front seat entertainment module for Porsche Cayenne GTS II (2010-2014)

Get access

AUDIO 1 GND AUDIO 1 L AUDIO 1 R AUDIO 2 GND AUDIO 2 L AUDIO 2 R AUDIO GND AUDIO L+ AUDIO R- AUDIO SHIELD BLK WIRE BLU WIRE BRN WIRE FUSE 40 GP-22 GP-31 GRN WIRE GRY WIRE HOT W/ PLUG SOCKETS RELAY ENERGIZED PORSCHE LEFT FRONT SEAT ENTERTAINMENT MODULE PORSCHE RIGHT FRONT SEAT ENTERTAINMENT MODULE RED/YEL WIRE RIGHT FUSE BOX TELEVISION TUNER TERM 30 TERM 31 VIDEO 1 GND VIDEO 1 SIG VIDEO 2 GND VIDEO 2 SIG VIDEO GND VIDEO SIGNAL VIO WIRE W/ TV TUNER W/O TV TUNER WHT WIRE YEL WIRE

Go to component: -> Rear seat entertainment circuit -> PORSCHE RIGHT FRONT SEAT ENTERTAINMENT MODULE
