Porsche Cayenne GTS II (2010-2014) park/neutral position Wiring diagram
This page shows the only wiring diagram for the component.park/neutral position, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park/neutral position (1 of 1)
AUTOMATIC TRANSMISSION
BACK/UP LT SW
BACKUP LIGHT
BACKUP SIGNAL
BLU/BLK WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DME CONTROL UNIT
FUSE 31
GP-26 (UNDER FRONT PASSENGER'S SEAT)
GP-40
GP-40 (NEAR RIGHT TAILLIGHT)
GP-41 (NEAR LEFT TAILLIGHT)
GRY/GRN WIRE
HOT AT ALL TIMES
INTERLOCK -
LEFT REAR LID TAIL LIGHT UNIT
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARK/NEUTRAL POSITION
REAR BCM
RED/BLU WIRE
RED/WHT WIRE
REVERSING LIGHT LEFT
REVERSING LIGHT RIGHT
REVERSING LIGHT/ REAR FOG LIGHT
RIGHT FUSE BOX
RIGHT REAR LID TAIL LIGHT UNIT
SWITCH PA
TERM 30
TERM 31
TRANSMISSION CONTROL UNIT
YEL/VIO WIRE
Go to component: -> Backup lamps circuit -> PARK/NEUTRAL POSITION
