Porsche Cayenne GTS II (2010-2014) optical waveguide out Wiring diagram
This page shows the only wiring diagram for the component.optical waveguide out, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram optical waveguide out (1 of 1)
AMPLIFIER (W/ BOSE) (RIGHT SIDE OF CARGO AREA)
AMPLIFIER (W/ BURMESTER) (RIGHT SIDE OF CARGO AREA)
ANTENNA
ANTENNA 1
ANTENNA 1 SHIELD
ANTENNA 2
ANTENNA 2 SHIELD
ANTENNA 3
ANTENNA 3 SHIELD
ANTENNA 4
ANTENNA 4 SHIELD
AUDIO GND
AUDIO L+
AUDIO R-
AUDIO SHIELD
BACKUP CAMERA CONTROL UNIT
BLK WIRE
BLU WIRE
BRK DIAG
BRN WIRE
BRN/WHT WIRE
FM IN
FM OUT
FUSE 24
GP-46
HOT AT ALL TIMES
LEFT SIDE WINDOW ANTENNA AMPLIFIER
OPTICAL WAVEGUIDE IN
OPTICAL WAVEGUIDE OUT
ORG/ WIRE
RB DIAGNOSIS
REAR SEAT ENTERTAINMENT CIRCUIT
RED/YEL WIRE
RIGHT ANTENNA AMPLIFIER
RIGHT FRONT FUSE CARRIER
RIGHT SIDE WINDOW ANTENNA AMPLIFIER
RING BRAKE DIAGNOSIS
SHIELD
TELEVISION TUNER (RIGHT SIDE OF CARGO AREA)
TERM 30
TERM 31
TV ANTENNA AMPLIFIER
VIDEO 2
VIDEO 2 GND
VIDEO GND
VIDEO GROUND
VIDEO OUT
VIDEO SIG
VIDEO SIGNAL
VIO WIRE
W/ RIGHT REAR FLAP W/O AMPLIFIER W/ AMPLIFIER
WHT WIRE
Go to component: -> Tv tuner circuit -> OPTICAL WAVEGUIDE OUT
