Porsche Cayenne GTS II (2010-2014) left rear wheel housing side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear wheel housing side impact sensor, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear wheel housing side impact sensor (1 of 1)
AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE)
AIR BAG TRIGGERING
BATT +
BELT TENSIONER +
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
C-PILLAR DRIVER +
C-PILLAR PASS +
CAN DIAGNOSTIC HI
CAN DIAGNOSTIC LO
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DIAGNOSTIC PLUG SOCKET
DISPOSAL LINE
DRIVER +
DRIVER DOOR
DRIVER KNEE AIR BAG
DRIVER SEAT POS
DRIVER SIDE REAR BELT TENSIONER
DRIVER SIDE REAR THORAX AIR BAG
DRIVER'S DOOR PRESSURE SENSOR
ESD GND
FR PASS DOOR +
FRONT PASSENGER DOOR PRESSURE SENSOR
FRONT PASSENGER SIDE REAR BELT TENSIONER
GRN WIRE
GRY WIRE
KNEE AIR BAG
LEFT FRONT SENSOR
LEFT REAR WHEEL HOUSING SIDE IMPACT SENSOR
NEGATIVE
NETWORK
OCCUPANCY DETECTION
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
PAO SWITCH L 1
PASSENGER
PASSENGER SIDE REAR THORAX AIR BAG
POSITIVE
PYROTECHNICAL BATT -
RED WIRE
RIGHT FRONT BELT BUCKLE
RIGHT FRONT SENSOR
RIGHT REAR WHEEL HOUSING SIDE IMPACT SENSOR
SEAT BELT TENSIONER +
SIG
TERM 15
TERM 51
THORAX AIR BAG
UP FRONT SNS +
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> LEFT REAR WHEEL HOUSING SIDE IMPACT SENSOR
