Porsche Cayenne GTS II (2010-2014) left rear side bolster heating element Wiring diagram
This page shows the only wiring diagram for the component.left rear side bolster heating element, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side bolster heating element (1 of 1)
A/C CONTROL UNIT
BACKREST HEATING ELEMENT
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOLSTER HEATER
BOLSTER HTR
BRN WIRE
BRN/WHT WIRE
FUSE 50
GP-22 (RIGHT SIDE OF DASH)
GP-26 (UNDER FRONT PASSENGER'S SEAT)
GP-30 (BASE OF RIGHT "B" PILLAR)
GP-31
GP-31 (BASE OF LEFT "B" PILLAR)
HEATER
HEATING ELEMENT BACKREST
HOT W/
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT FRONT SEAT CUSHION HEATING ELEMENT
LEFT HTR SEAT
LEFT REAR BACKREST BOLSTER HEATING ELEMENT
LEFT REAR SEAT BACKREST HEATING ELEMENT
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SIDE BOLSTER HEATING ELEMENT
NTC-
REAR OPERATING, A/C UNIT
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT FUSE BOX
RIGHT HTR SEAT
RIGHT REAR BACKREST BOLSTER HEATING ELEMENT
RIGHT REAR SEAT BACKREST HEATING ELEMENT
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SIDE BOLSTER HEATING ELEMENT
SEAT HTR LH
SEAT HTR RH
SEAT TEMP LEFT
SEAT TEMP SENS LH
SETA TEMP RIGHT
SIDE BOLSTER HEATING
SIG GND
SIGNAL GND
TEMP SENS RH
TERMINAL 31
WHT/YEL WIRE
YEL WIRE
Go to component: -> Rear seat heater circuit -> LEFT REAR SIDE BOLSTER HEATING ELEMENT
