Porsche Cayenne GTS II (2010-2014) left rear shock absorbers valve Wiring diagram

AIR SPRING VLV FL- AIR SPRING VLV FR- AIR SPRING VLV RL- AIR SPRING VLV RR- AXLE HEIGHT BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLOW-OUT VLV - BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/WHT WIRE CHANGE-OVER UNIT 1 LS CHANGE-OVER UNIT 1, 2 HS CHANGE-OVER UNIT 2 LS COMPRESSOR RLY + HIGH COMPRESSOR RLY - LOW FRONT BCM FUSE 2 GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRY WIRE HEIGHT SENS HOT AT ALL TIMES INPUT SENS LEFT REAR HEIGHT SENSOR LEFT REAR SHOCK ABSORBERS VALVE LEVEL SENS RL SIG LEVEL SENS RR SIG LEVEL SENS RR+ LEVEL SENSOR RL+ PASM CONTROL UNIT (RIGHT SIDE OF CARGO AREA) PRESS SENS PRESSURE SENS + PWM RED/WHT WIRE RED/YEL WIRE RIGHT FUSE BLOCK RIGHT REAR HEIGHT SENSOR RIGHT REAR SHOCK ABSORBERS VALVE SHOCK ABSORBERS VLV RL+ SHOCK ABSORBERS VLV RR+ SIG PRESS SENS SIG PRESSURE SENS SOLENOID BLOCK SPLY SPLY PRESSURE SENS SPLY, VLVS SUPER CHARGER LEVEL CONTROL TERM 30 TERM 30 ENG TERM 31 TERM 31 ENG VLV 1 GND LS VLV 2 GND LS WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
