Porsche Cayenne GTS II (2010-2014) left front brake pad wear indicator Wiring diagram
This page shows the only wiring diagram for the component.left front brake pad wear indicator, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front brake pad wear indicator (1 of 1)
2/3-WAY VALVE
3.0L HYBRID
ACC CONTROL UNIT
BLK WIRE
BRN WIRE
CIRCULATING PUMP AUXILIARY HEATER
ELECTRIC A/C COMPRESSOR
ELECTRIC DRIVE
ELECTRIC DRIVE POWER ELECTRONICS
ENGINE LID SWITCH
GP-5 (BEHIND LEFT HEADLIGHT)
GP-6 (BEHIND RIGHT HEADLIGHT)
GP-MB DC
GP-MB EM
GP-MB HV
GP-MB LE
HEADLIGHT WASHER FLUID PUMP
HIGH VOLTAGE BATTERY SYSTEM
LEFT AUXILIARY HEADLIGHT
LEFT FRONT BRAKE PAD WEAR INDICATOR
LEFT FRONT FOG LIGHT
LEFT FRONT HEATED SPRAY JET
LEFT HEADLIGHT
LEFT SIDE TURN SIGNAL
LEFT TWO-TONE HORN
PARKING HEATER CONTROL UNIT
RIGHT AUXILIARY HEADLIGHT
RIGHT FRONT FOG LIGHT
RIGHT FRONT HEATED SPRAY JET
RIGHT HEADLIGHT
RIGHT SIDE TURN SIGNAL
RIGHT TWO-TONE HORN
SPINDLE ACTUATOR
TRANSMISSION OIL PUMP DRIVER
W/ DRL
W/O DRL
YEL WIRE
Go to component: -> Ground distribution circuit (1 of 6) -> LEFT FRONT BRAKE PAD WEAR INDICATOR
