Porsche Cayenne GTS II (2010-2014) lbk sensor flap valve 1 Wiring diagram

BLK WIRE BLU WIRE BOOST PRESSURE SENSOR 1 BOOST PRESSURE SENSOR 2 BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BYPASS COMPRESSOR COOLANT RETURN TEMPERATURE SENSOR COOLANT TEMPERATURE SENSOR FUEL LOW PRESSURE SENSOR FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 3 FUSE 4 FUSE 7 FUSE 8 FUSE 9 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HOT AT ALL TIMES INTAKE-MANIFOLD PRESSURE SENSOR JUMP START POINT KNOCK SENSOR #2 LBK SENSOR FLAP VALVE 1 LBK SENSOR FLAP VALVE 2 MTR NTC- OUTPUT PLENUM PANEL FUSE BOX RAIL PRESSURE SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SECONDARY AIR PRESS SENSOR SENS SENS GND SENS SIG SHIELD SIG SPLY TERM 31 VCC WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
