Porsche Cayenne GTS II (2010-2014) hot w/ term 15 relay energized Wiring diagram

This page shows the only wiring diagram for the component.hot w/ term 15 relay energized, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram hot w/ term 15 relay energized (1 of 1)

Wiring diagram hot w/ term 15 relay energized for Porsche Cayenne GTS II (2010-2014)

Get access

ALL-WHEEL DRIVE CONTROL UNIT BLK WIRE BLK/RED WIRE BRN WIRE CAN DRIVE HIGH CAN DRIVE LOW COMPUTER DATA LINES SYSTEM FUSE 12 FUSE 30 FUSE 43 GP-26 HOT AT ALL TIMES HOT W/ TERM 15 RELAY ENERGIZED ORG/BRN WIRE ORG/RED WIRE RED WIRE RED/WHT WIRE RIGHT FUSE BOX TERM 15 TERM 30 TERM 31 GND TERMINAL 30 WHT WIRE

Go to component: -> Awd circuit -> HOT W/ TERM 15 RELAY ENERGIZED
