Porsche Cayenne GTS II (2010-2014) hi volt minus Wiring diagram
This page shows the only wiring diagram for the component.hi volt minus, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi volt minus (1 of 1)
BATTERY COOLING RELAY
BLK WIRE
BLK/RED WIRE
BLOWER
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
CAN DRIVE HI
CAN DRIVE LOW
CAN HIGH
CAN HYBRID HI
CAN HYBRID LOW
CAN LOW
COMPUTER DATA LINES SYSTEM
CONTACT 2 IN
CONTACT 2 OUT
CRASH GND
CRASH SIG
EQUALISATION
FAN 1 FEEDBACK
FAN 1 PWM
FAN 2 FEEDBACK
FAN 2 PWM
FAN RELAY
FEEDBACK
FUSE 1
FUSE 2
GP-1
GP-41
GP-41 (NEAR LEFT TAILLIGHT)
GP-5
GP-MB HV
GRN/BLK WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY/RED WIRE
GRY/VIO WIRE
HI VOLT MINUS
HI VOLT PLUS
HIGH VOLTAGE BATTERY SYSTEM
HOT AT ALL TIMES
JUMP START POINT
LEFT BATTERY FAN
LEFT TOP LOADER
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/WHT WIRE
PILOTLINE IN
PILOTLINE OUT
POWER STEERING PUMP
PWM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RIGHT BATTERY FAN
SHIELD
SPINDLE ACTUATOR
SUPPLEMENTAL RESTRAINTS SYSTEM
TERM 15
TERM 30
TERM 31
VIO WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component: -> Wiring diagram engine performance 3.0l hybrid (8 of 9) -> HI VOLT MINUS
