Porsche Cayenne GTS II (2010-2014) glow pin control unit Wiring diagram
This page shows the only wiring diagram for the component.glow pin control unit, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glow pin control unit (1 of 1)
3.0L DIESEL
3.0L HYBRID
3.0L HYBRID 3.6L, 4.8L, 4.8L TURBO 3.0L DIESEL
ALARM SIREN
BAR IGNITION MODULE CYLINDER 1
BAR IGNITION MODULE CYLINDER 2
BAR IGNITION MODULE CYLINDER 3
BAR IGNITION MODULE CYLINDER 4
BAR IGNITION MODULE CYLINDER 5
BAR IGNITION MODULE CYLINDER 6
BAR IGNITION MODULE CYLINDER 7
BAR IGNITION MODULE CYLINDER 8
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
DME CONTROL UNIT
FRONT WIPER MOTOR
GLOW PIN CONTROL UNIT
GP-1
GP-12
GP-13
GP-14
LOW TEMPERATURE WATER PUMP CIRCUIT
OIL LEVEL SENSOR
OIL LEVEL SENSOR SHIELD
OIL PRESSURE SWITCH 2
POWER STEERING PUMP
PSM CONTROL UNIT
RADIATOR FAN
REFRIGERANT PRESSURE SENSOR
SECONDARY AIR PUMP
THEFT PROTECTION ALARM HORN
THROTTLE VALVE ADJUSTMENT UNIT
TO GROUND GP-12 (DIAGRAM 2 OF 7)
VACUUM PUMP
WATER PUMP HIGH TEMPERATURE CIRCUIT
WATER PUMP LOW TEMPERATURE CIRCUIT
Go to component: -> Ground distribution circuit (2 of 6) -> GLOW PIN CONTROL UNIT
